ATF System with C410:V3 Controller
1.2 XCell
TM
ATF System Control Scope and Objectives:
The C40:V3 controller provides the process control functionality of the XCell
TM
ATF4,
ATF6, and ATF10 Systems. The C410:V3 controller is designed to:
1. Control ATF flow rates in both pressure and exhaust phases
2. Provide a user interface capability for XCell
TM
ATF System control and monitoring
3. Set-up and select operation parameters
4. Display real-time process data
5. Alarm for error conditions
6. Provide “batch control” and user hierarchy
7. Have PLC software upgrades in the field by replacing memory modules
8. Have two major components, an Electronics Box (E-Box) and a Pneumatics Box (P-
Box)
9. Allow the E-Box to operate an XCell
TM
ATF4, ATF6, or ATF10 System using specific
software and modules.
10. Allow the P-Box hardware and process parameters to be specific to the size of the
particular XCell
TM
ATF System being controlled.
1.3 XCell
TM
ATF Pump Housing and Controller Pairings
XCell
TM
ATF4
Stainless Steel
C410:V3 C410 controller for XCell
TM
ATF4
system with air tubing.
C410:V3 C410 controller for XCell
TM
ATF4
system with air tubing and standard GMP
Profibus configured C410-V4B controller with
power separation for XCell
TM
ATF4 system with
air tubing, standard GMP documents and FAT.
XCell
TM
ATF6
Stainless Steel and
Single-use
C410:V3 C410 controller for XCell
TM
ATF6
system with air tubing.
C410:V3 C410 controller for XCell
TM
ATF6
system with air tubing, standard GMP
Profibus configured C410-V4B controller with
power separation for XCell
TM
ATF4 system with
air tubing, standard GMP documents and FAT.
XCell
TM
ATF10
Stainless Steel and
Single-use
C410:V3 C410 controller for XCell
TM
ATF6
system with air tubing.
C410:V3 C410 controller for XCell
TM
ATF10
system with air tubing, standard GMP
Profibus configured C410-V4B controller with
power separation for XCell
TM
ATF10 system
with air tubing and standard GMP
