ATF System with C410:V3 Controller
User Guide
User Level
Option
Controller Function
Parameter
Permissions
Slope Function
Enabled
Allowed to adjust
Bioreactor
Pressure
Allowed to adjust
Height
Differential
Allowed to adjust
Pump Parameters
Pressure Offset
Allowed to adjust
pressure and exhaust
cycle fields
Delay Time
Allowed to adjust
pressure and exhaust
cycle fields
Over Time
Allowed to adjust
pressure and exhaust
cycle fields
PV Step Size
Allowed to adjust
pressure and exhaust
cycle fields
Alarm Set Points
P2 Pressure
Allowed to adjust
HiHi and LoLo Fields
Alarm Delay
Allowed to adjust
HiHi and LoLo Fields
Set Up-
Advanced
User Set Point
Ranges
Pressure Cycle
Flow Max
Allowed to Adjust
LPM and Seconds
field
Pressure Cycle
Flow Min
Allowed to Adjust
LPM and Seconds
field
Exhaust Cycle
Flow Max
Allowed to Adjust
LPM and Seconds
field
Exhaust Cycle
Flow Min
Allowed to Adjust
LPM and Seconds
field
Accept Changes
Allowed
Discard
Changes
Allowed
Output (CV) Limits PV1(%)
Allowed to adjust
min and max
