XCell ATF Series User Manual

80
XCell
TM
ATF System with C410:V3 Controller
Alarm List
Tag
Description
PLC Address
Alarm
Enable
Condition
Delay
Action
"DB1"
.ALARM_REG(0)
XCell™ ATF Warning
condition has not been
reset within the alarm
delay time, XCell™ ATF
function halted.
%DB1
.DBX110.0
Pump is Running
and Alarm Delay
Timer Setpoint
is Greater than
Zero.
*See Note
1 min
Alarm, System
Stop, Activate
System Fault
Warning Horn
"DB1"
.ALARM_REG(1)
Main Power Loss
(120/220) while Pump
was running
%DB1
.DBX110.1
First Scan of PLC
on Power Up.
On first scan
Pump State is
not 0
N/A
Alarm, System
Stop, Activate
System Fault
Warning Horn
"DB1"
.ALARM_REG(2)
P2 Pressure Above HI
HI Limit
%DB1
.DBX110.2
Pump is Running
P2 pressure is
greater than or
equal to the P2
Hi HI Pressure
alarm setpoint.
P2 Hi Hi Set
Point Alarm
Delay in
10ms
increments
.
Alarm, System
Stop, Activate
System Fault
Warning Horn
"DB1"
.WARN_REG(0)
Flow Set Point
cannot be reached. Air
Supply Regulator
(PRV1) above maximum
pressure setting
%DB1
.DBX132.0
Pump is Running
PRV1>=PRV1
MAX
N/A
Warning,
Activate System
Fault Warning
Horn
"DB1"
.WARN_REG(1)
Flow Set Point
cannot be reached. Air
Supply Regulator
(PRV1) below minimum
pressure setting
%DB1
.DBX132.1
Pump is Running
PRV1<=PRV1
MIN
N/A
Warning,
Activate System
Fault Warning
Horn
"DB1"
.WARN_REG(2)
Exhaust Set Point
cannot be reached.
Vacuum Supply
Regulator (PRV2) above
maximum vacuum
setting
%DB1
.DBX132.2
Pump is Running
PRV2>=PRV2
MAX
N/A
Warning,
Activate System
Fault Warning
Horn
"DB1"
.WARN_REG(3)
Exhaust Set Point
cannot be reached.
Vacuum Supply
Regulator (PRV2) below
minimum vacuum
setting
%DB1
.DBX132.3
Pump is Running
PRV2<=PRV2
MIN
N/A
Warning,
Activate System
Fault Warning
Horn
"DB1"
.WARN_REG(4)
P2 Pressure below Lo
Lo Limit
%DB1
.DBX132.0
Pump is Running
P2_PV <=
Pressure Alarm
Lo Lo Setpoint
P2 Lo Lo
Set Point
Alarm
Delay in
10ms
increments
.
Warning,
Activate System
Fault Warning
Horn
