XCell ATF Series User Manual

82
XCell
TM
ATF System with C410:V3 Controller
User Guide
XCell™ ATF 6 Pump Housing Spares
A6-H1
Filter Housing Assembly, XCell™ ATF6
A6:R1
Reducer, XCell™ ATF6
XCell™ ATF6:PHLA
Pump Hemisphere, Liquid Side Assembly, XCell™ ATF6
A6-BASE
Pump Hemisphere, Base Plate, Assembly, XCell™ ATF6
SG-05-E
Sanitary Gasket, 1/2" TC
SG-075-E
Sanitary Gasket, 3/4" TC
SG-1.5-E
Sanitary Gasket, 1 1/2" TC
O:337-S-GMP
Silicone Size 337 70A O-Ring
TC:PG:3/4
Pressure Gauge, 3/4 TC 30PSI to - 30" Hg
TC-EL1S
Elbow 90 Degree -1.0 , TC Ends
SG-1.0-E
Sanitary Gasket 1" TC
TC:W2-1.5
Window, Sanitary 1.5"TC, w/Rem. Glass Insert
TC-CAP-3/4
Sanitary Cap 3/4"
V1-S-0.5N
Sanitary Diaphragm Valve, 1/2" w/TC ends
SC-075
Clamp, Sanitary, 1/2"-3/4" TC
SC-1.5
Clamp, Sanitary, 1 1/2" TC
A6-BASE-SHCS
1/4-20x3/8 Socket Head Cap Screw (4)
SC-3L
Clamp, Sanitary, 3.0" TC
SC-6.0
Clamp, Sanitary 6.0" TC
TC-BRB1
Sanitary Adapter, 3/4" Tri-Clamp x 1/4" Hose Barb Fitting
XCell™ ATF6:AIR-ASSY
Air Inlet Assembly, XCell™ ATF6
P3-CPM1.5-TC3/4
Kit, PT, 1.5"CPM Fitting, 3/4"TC
XCell™ ATF6:PH-AA-AIR
Air Hemisphere, XCell™ ATF6 w/XCell™ ATF6:AIR-ASSY
XCell™ ATF 10 Pump Housing Spares
A10-STAND
Stand, Assembly, XCell™ ATF10
A10RF-C3
ASME Clamp, Assembly, XCell™ ATF10
A10RF-H1
Filter Housing Assembly, XCell™ ATF10
A10RF:HA
Lifting Handle, Assembly, XCell™ ATF10
XCell™ ATF10:PHLA
Pump Hemisphere Liquid Side, Assembly, XCell™ ATF10
A10-R1
Reducer, XCell™ ATF10
A10RF-C3-RELIEF
ASME Clamp w/ Relief, Assembly, XCell™ ATF10
A10:C1-LOCK-A
C Clamp w/ Lock-A, Assembly, XCell™ ATF10
A10:C1-LOCK-B
C Clamp w/ Lock-B, Assembly, XCell™ ATF10
SG-05-E
Sanitary Gasket, 1/2" TC
SG-075-E
Sanitary Gasket, 3/4" TC
SG-1.5-E
Sanitary Gasket, 1 1/2" TC
TC-W2-1.5
Window, Sanitary 1.5"TC, With / Rem. Glass Insert 316L SS/Glass
TC-CAP-3/4
Sanitary Cap 3/4"
TC-EL-1.5S
90 Degree Ell, 1.5TC
TC-PG-1.5
Pressure Gauge, 1.5 TC, 30 psi
V1-S-0.5N
Sanitary Diaphragm Valve, 1/2" w/TC ends
SC-075
Clamp, Sanitary 1/2-3/4" TC
SC-1.5
Clamp, Sanitary, 1 1/2" TC
O-CTM-10H
O-Ring, 50 Duro, Clear, 0.295" C/S x 6.835" ID x 7.425" OD
