September 2001 88XX Series Folder Operator Manual 26
Go to the “LENGTH” submenu [ U6.03 ].
Press “Enter” to show the number of the last length selected. To
modify the length value, use the Scroll keys. When you have
reached the desired value, press “Enter”.
On the Alphanumeric Control Panel, the selection of the length
is easier:
− Use the Scroll keys to increase/decrease the length of 1mm
steps.
− Depressing the “Pause” key and actuating the Scroll keys
will increase/decrease only the firsts two digits. This method
will allow faster access to the desired value.
4. After the last setting, go to the “FEED IN” message [U6.06], but
do not press “Enter”. Let the display show “FEED IN” message,
which allows the Bridge Entry Flap to go down.
5. Lift the bridge level to the top of the printer as shown in the picture.
The safety lever will support it.
6. From the top of the printer, feed the document into the folder. When
the entry sensor is actuated, the bridge starts feeding the print.
112763
FEED THE PRINTS ALWAYS WITH THE TITLE BLOCK:
LOCATION 4 FOR ISO/AN SI/ARCH SIZES
LOCATION 1 FOR AFNOR
LOCATION 2 FOR ERICSSON
FEED THE PRINTS ALWAYS SEF (SHORT EDGE
FEEDING)
Bridge in offline
position with 8830
