Xerox B1022 System Administrator Guide

802.1X
802.1X is an Institute for Electrical and Electronics Engineers (IEEE) standard that defines a method
for port-based network access control or authentication. In an 802.1X secured network, the printer
must be authenticated by a central authority, typically a RADIUS server, before it can access the
physical network.
You can enable and configure the printer to be used in an 802.1X secured network from the printer
control panel or in Xerox
®
CentreWare
®
Internet Services.
Before you begin:
• Ensure that your 802.1X authentication server and authentication switch are available on the
network.
• Determine the supported authentication method.
• Create a user name and password on your authentication server.
Note: This procedure causes the printer to restart and be unavailable over the network for
several minutes.
CCoonnffiigguurriinngg 880022..11XX iinn XXeerrooxx
®®
CCeennttrreeWWaarree
®®
IInntteerrnneett
SSeerrvviicceess
1. In Xerox
®
CentreWare
®
Internet Services, click Properties→Security.
2. Click 802.1X.
3. For 802.1X, select Enabled.
4. For Authentication Method, select an option.
5. For Credentials, type the user name and password.
6. To upload a root certificate, do the following steps.
a. For Upload Root Certificate, to locate and select the file, click Browse or Choose File.
b. Click Upload.
7. To upload a client certificate, do the following steps.
a. To locate and select the Client Certificate, for Upload Client Certificate, click Browse or
Choose File.
b. To assign a private password, for Private Key Password, type a password.
c. Click Upload.
8. Click Apply.
EEnnaabblliinngg aanndd CCoonnffiigguurriinngg 880022..11XX aatt tthhee CCoonnttrrooll PPaanneell
Note:
• When the printer is in FIPS 140 mode, EAP-TLS authentication is required.
• To configure 802.1X settings for EAP-TLS, use Xerox
®
CentreWare
®
Internet Services.
52
Xerox
®
B1022 Multifunction Printer
System Administrator Guide
Security

Xerox B1022 Specifications

General

Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Watermark printing	Yes
Time to first page (black, normal)	9.1 s
Print speed (black, normal quality, A4/US Letter)	22 ppm
Duplex print speed (black, normal quality, A4/US Letter)	11 ppm
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	999 copies
Time to first copy (black, normal)	7.8 s
Copy speed (black, normal quality, A4)	22 cpm
Faxing	No
Scan to	E-mail, FTP, PC, SMB, USB
Scan drivers	TWAIN, WIA
Scanner type	Flatbed scanner
Maximum scan area	297 x 432 mm
Image formats supported	JPG, TIFF
Document formats supported	PDF
Total input capacity	350 sheets
Total output capacity	250 sheets
Maximum input capacity	600 sheets
Sound power level (standby)	30 dB
Wi-Fi	-
Cabling technology	10/100Base-T(X)
Ethernet LAN data rates	10, 100 Mbit/s
Optional connectivity	Wireless LAN
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	1100 W
Power consumption (off)	2 W
Power consumption (ready)	80 W
Power consumption (sleep)	1 W
Power consumption (average operating)	550 W
Energy Star Typical Electricity Consumption (TEC)	1.2 kWh/week
Storage temperature (T-T)	-20 - 40 °C
Operating temperature (T-T)	10 - 30 °C
Operating relative humidity (H-H)	20 - 80 %
Product color	Black, White
Market positioning	Business
Package depth	750 mm
Package width	771 mm
Package height	600 mm
Package weight	32000 g
Maximum duty cycle	50000 pages per month
Number of print cartridges	1
Page description languages	PCL 6, PostScript
Paper tray media types	Bond paper, Heavy paper, Letterhead, Plain paper
Non-ISO print media sizes	Executive (184 x 267mm), Legal (media size), Letter (media size), Statement (140 x 216mm), Tabloid (media size)
ISO A-series sizes (A0...A9)	A3, A4, A5
ISO B-series sizes (B0...B9)	B4
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A3
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra
Server operating systems supported	Windows 2000 Server, Windows Server 2003, Windows Server 2008, Windows Server 2008 R2, Windows Server 2012
Windows operating systems supported	Windows 10, Windows 7, Windows 8
Included cartridge capacity (black)	2500 pages

Weight and Dimensions

Depth	555.3 mm
Width	560 mm
Height	417 mm
