Xerox DocuMate 162 User Manual

DocuMate 162 Scanner User’s Guide 19
Scanning
Loading Documents to Scan
When you press either the Simplex or Duplex button, documents are
scanned using the scan settings indicated by the LED number. The
scanned images are then sent to a software application on your
computer.
1. Adjust the paper guide for the width of paper, and make sure the input
and output trays are fully extended.
2. Load the documents face down with the top of the pages inserted into
the Automatic Document Feeder.
NOTE: Always remove any staples or paper clips from documents
before inserting them into the scanner’s Automatic Document Feeder.
Staples and paper clips can jam the feed mechanism and scratch the
internal components. Also remove any labels, stickers, or Post-It™
notes that may come off during the scanning process and get stuck in
the scanner. Misuse as described here will void your scanner’s
warranty.

Xerox DocuMate 162 Specifications

General

Film scanning	No
Color scanning	Yes
Input color depth	24 bit
Maximum scan size	216 x 356 mm
Optical scanning resolution	600 x 600 DPI
Scanner type	Sheet-fed scanner
Sensor type	CCD
Maximum duty cycle	90000 pages per month
ISO A-series sizes (A0...A9)	A4
Auto document feeder (ADF) input capacity	50 sheets
Scan media weight	60 - 105 g/m²
Dimensions (WxDxH)	309 x 160 x 141 mm
Standard media sizes	51mm x 89mm(2\
Dimensions (W x D x H) (imperial)	12.1 x 6.3 x 5.5 \
USB version	2.0
Standard interfaces	USB 2.0
Bundled software	Kofax VRS Nuance PaperPort OmniPage Pro EMC/Captiva QuickScan Demo NewSoft Presto! BizCard
Minimum RAM	512 MB
Minimum processor	Pentium IV
Minimum storage drive space	350 MB
Minimum system requirements	DVD-ROM, USB
Compatible operating systems	Windows 2000 (SP4) / XP (SP2) / Vista

Weight and Dimensions

Depth	160 mm
Width	309 mm
Height	141 mm
Weight	2900 g
