Scanning with the ISIS Interface
68 DocuMate 162 Scanner User’s Guide
Scanning with the ISIS
Interface
You can use the ISIS interface from QuickScan™ or any other application
that will access the ISIS driver. Note that the ISIS interface for each
application varies depending on the application. Please refer to that
software application’s User Guide for instructions on scanning with the
ISIS interface.
Accessing the ISIS Interface in QuickScan
1. Open the QuickScan software to access the ISIS driver scanning
options.
Please note that you may see the following warning message:
2. Please disregard this message and click Continue.
The ISIS drivers were installed correctly during the installation of your
Xerox DocuMate 162 scanner.
3. The Scanner Selection dialog box will then open.
4. Select Xerox DocuMate 162 from the list of scanners and click OK.
5. Your scanner is now ready to work with QuickScan.

Xerox DocuMate 162 Specifications

General

Film scanning	No
Color scanning	Yes
Input color depth	24 bit
Maximum scan size	216 x 356 mm
Optical scanning resolution	600 x 600 DPI
Scanner type	Sheet-fed scanner
Sensor type	CCD
Maximum duty cycle	90000 pages per month
ISO A-series sizes (A0...A9)	A4
Auto document feeder (ADF) input capacity	50 sheets
Scan media weight	60 - 105 g/m²
Dimensions (WxDxH)	309 x 160 x 141 mm
Standard media sizes	51mm x 89mm(2\
Dimensions (W x D x H) (imperial)	12.1 x 6.3 x 5.5 \
USB version	2.0
Standard interfaces	USB 2.0
Bundled software	Kofax VRS Nuance PaperPort OmniPage Pro EMC/Captiva QuickScan Demo NewSoft Presto! BizCard
Minimum RAM	512 MB
Minimum processor	Pentium IV
Minimum storage drive space	350 MB
Minimum system requirements	DVD-ROM, USB
Compatible operating systems	Windows 2000 (SP4) / XP (SP2) / Vista

Weight and Dimensions

Depth	160 mm
Width	309 mm
Height	141 mm
Weight	2900 g
