Xerox DocuMate 162 User Manual

DocuMate 162 Scanner User’s Guide 51
Scanning
Scan and Burn to a CD
If you have a CD burner attached to your computer, you can scan directly
from your scanner onto a CD. This feature is available only on computers
running Windows XP or Windows Vista.
1. Open the One Touch Properties window.
2. Choose a button to use for scanning and burning to a CD.
3. Select Burn to CD as the Destination Application.
4. Choose a Format and a Scan Configuration.
5. Click OK.
6. Now start scanning using the button you selected to use to scan and
burn to a CD.
When scanning is finished, a bubble message on the screen tells you
that files are waiting to be burned to the CD.
7. Open the One Touch window, select Burn to CD and click the
Properties button.
The One Touch 4.0 Link Properties window opens
8. Make sure a blank CD is in the CD burner.
9. Click the Burn to CD button. The CD burner begins and your
scanned documents are written to the CD.
NOTE: If other files are also waiting to be burned to the CD, they will
get written with the One Touch files on the CD.

Xerox DocuMate 162 Specifications

General

Film scanning	No
Color scanning	Yes
Input color depth	24 bit
Maximum scan size	216 x 356 mm
Optical scanning resolution	600 x 600 DPI
Scanner type	Sheet-fed scanner
Sensor type	CCD
Maximum duty cycle	90000 pages per month
ISO A-series sizes (A0...A9)	A4
Auto document feeder (ADF) input capacity	50 sheets
Scan media weight	60 - 105 g/m²
Dimensions (WxDxH)	309 x 160 x 141 mm
Standard media sizes	51mm x 89mm(2\
Dimensions (W x D x H) (imperial)	12.1 x 6.3 x 5.5 \
USB version	2.0
Standard interfaces	USB 2.0
Bundled software	Kofax VRS Nuance PaperPort OmniPage Pro EMC/Captiva QuickScan Demo NewSoft Presto! BizCard
Minimum RAM	512 MB
Minimum processor	Pentium IV
Minimum storage drive space	350 MB
Minimum system requirements	DVD-ROM, USB
Compatible operating systems	Windows 2000 (SP4) / XP (SP2) / Vista

Weight and Dimensions

Depth	160 mm
Width	309 mm
Height	141 mm
Weight	2900 g
