Xerox DocuMate 515 User Manual

Scanning from the TWAIN Interface
70 DocuMate 515 Scanner User’s Guide
This example shows a manually selected area
The ruler units
The ruler around the edges of the image help you precisely position a
custom sized image. You can change the ruler units to suit the type of
measurements you want.
Click the Ruler Units
button. The ruler units across the top and down the
side of the window cycle through centimeters, inches, and pixels.
The Scan Info Box
The following figure shows the information on the Scan Info box.
The Scan Info box shows the
size and position of the area.
The selected scan area.
This is the image that appears
on the PaperPort desktop
when scanning is finished.
Location of the top
left corner of the
image in the
Preview window.
Physical size of the
image to scan.
Size of the file of the
scanned image.
The space on your
computer’s hard drive.
Current location of
the pointer as you
drag it on the
Preview window.
Tabs for each selected area. Click a tab
to see the information for its area.
Click to remove the
selected area.

Xerox DocuMate 515 Specifications

General

Film scanning	No
Color scanning	Yes
Grayscale levels	65536
Input color depth	24 bit
Maximum scan size	216 x 356 mm
Scanner type	ADF scanner
Auto document feeder (ADF) input capacity	50 sheets
USB version	2.0
Standard interfaces	USB 2.0
Minimum RAM	512 MB
Minimum storage drive space	350 MB
Maximum duty cycle	75000 pages per month
Country of origin	China
Scan media weight	52 - 127 g/m²
Dimensions (WxDxH)	445 x 330 x 178 mm
Box depth (imperial)	19.7 \
Box width (imperial)	15.7 \
Box height (imperial)	4.9 \
Package width	398.779 mm
Package height	124.459 mm
Package length	500.379 mm
Package weight	3900.9 g
ISO A-series sizes (A0...A9)	A4

Weight and Dimensions

Depth	330 mm
Width	445 mm
Height	178 mm
Weight	5200 g
