DocuMate 515 Scanner User’s Guide 71
Scanning from the TWAIN Interface
Creating a New Advanced Interface Profile
You can create and save Advanced Interface profiles.
To create a new profile:
1. Select one of the preset profiles, for example Custom.
2. Adjust the settings and click the Save As button.
3. Type a name for the new profile and click OK. The name must be at
least two characters long.
To change or delete a profile you created:
1. Select your profile from the configuration list.
2. Make changes to the profile as needed, and then click Save.
3. If you want to delete the selected profile, click Delete.
Display the Device Configuration
Click the Device Configuration button on the Advanced Interface.
The Device configuration window opens and shows the information about
your scanner.
See the section “Checking the Hardware and Setting the Lamp Power
Saving” on page 58 for more information about the device settings.

Xerox DocuMate 515 Specifications

General

Film scanning	No
Color scanning	Yes
Grayscale levels	65536
Input color depth	24 bit
Maximum scan size	216 x 356 mm
Scanner type	ADF scanner
Auto document feeder (ADF) input capacity	50 sheets
USB version	2.0
Standard interfaces	USB 2.0
Minimum RAM	512 MB
Minimum storage drive space	350 MB
Maximum duty cycle	75000 pages per month
Country of origin	China
Scan media weight	52 - 127 g/m²
Dimensions (WxDxH)	445 x 330 x 178 mm
Box depth (imperial)	19.7 \
Box width (imperial)	15.7 \
Box height (imperial)	4.9 \
Package width	398.779 mm
Package height	124.459 mm
Package length	500.379 mm
Package weight	3900.9 g
ISO A-series sizes (A0...A9)	A4

Weight and Dimensions

Depth	330 mm
Width	445 mm
Height	178 mm
Weight	5200 g
