7.1 Replacing Consumables 131
3. Hold the knobs of the feed roller cover and
open the cover.
4. Turn the feed roller until the roller hook can
be seen.
5. Pull the feed roller hook out of the notch in
the axle, and then slide the feed roller to the
right.
6. Align the hole of the new feed roller with the
axle.
7. Slide the feed roller along the axle so the
protrusions fit completely into the slots on
the axle.
