22 1 Printer Environment Settings
Connecting a cable
Connect the printer to your computer using an
interface cable appropriate for your connection
method.
An interface cable is not included with the printer.
You must purchase it separately.
USB Connection
When using a USB connection, install the print
driver on your computer before connecting the
cable. For installation instructions, refer to the
“Installing a Print Driver” (P. 29) or the ‘CD-ROM
Documentation (HTML)’ on the Driver CD Kit CD-
ROM.
1. Switch the printer off.
2. Plug the USB cable into the interface
connector on the printer.
3. Plug the other end of the USB cable into your
computer.
4. Switch the printer on.
Network Connection
Use a straight-type network cable that supports
100BASE-TX or 10BASE-T.
1. Switch the printer off.
2. Plug the network cable into the interface
connector on the printer.
3. Plug the other end of the network cable into
a network device such as a hub.
4. Switch the printer on.
Parallel Connection
When using a parallel connection, you must first
install the optional Parallel Port and connector
conversion cable.
1. Switch the printer off.
2. Insert the connector conversion cable
included with the optional Parallel Port into
the interface connector on the printer.
3. Connect the other end of the connector
conversion cable to the connector on the
parallel cable. Then secure it using the metal
pieces on both sides of the connector.
4. Plug the other end of the parallel cable into
your computer.
5. Switch the printer on.
