8-24 Phaser 3140/3155/3160 Printer Service Manual
Service Parts Disassembly
2. Remove 2 screws (10 mm, silver, tap) on the front of the printer.
3. Open the Rear Cover.
4. Remove 2 screws (10 mm, silver, tap) on the rear of the printer.
s3160-157
s3160-017
