Paper and Other Media
Xerox Phaser 4622
User Guide
58
3. Squeeze the rear and side guides and move from the current
position and into the correct position for the current paper
size. Make sure the guides click into place.
4. Close the paper tray.
5. After loading paper in the paper tray, set the paper size, type
and color using the control panel. Press OK to confirm the
settings or Stop to change the settings.
For instructions, refer to Tray Paper Settings on page 61.
6. When printing from your PC, ensure you select the Paper
button to specify the correct paper size, color and type. Not confirming the paper details may
result in printing delays.
High Capacity Feeder (optional)
The optional High Capacity Feeder can hold up to 2000 sheets and is intended to be the primary
feeder for the most commonly used media. Acceptable print media is plain paper from A4/Letter to
Legal size (210 x 298 mm / 215 x 279 mm to 216 x 356 mm) and weighing between 16 lb and 43 lb
(60 g/m² and 163 g/m²).
1. Opening the tray door automatically lowers an elevator in
the base of the tray.
2. Squeeze the guide and move from the current position into
the correct position for the paper being loaded. Make sure
the guide clicks into place.
3. Place the media in the tray.
Paper must not be loaded above the Maximum Fill line.
Note The High Capacity Feeder can hold a maximum of
2000 sheets of 20 lb (80 g/m²) bond paper.
4. Close the tray door. When the door is closed the elevator rises
to feed the media.
5. After loading paper in the paper tray, set the paper size, type and color using the control panel.
Press OK to confirm the settings or Stop to change the settings.
For instructions, refer to Tray Paper Settings on page 61.
6. When printing from your PC, ensure you select the Paper button to specify the correct paper size,
color and type. Not confirming the paper details may result in printing delays.
