Parts of the Printer
Phaser® 7760 Color Laser Printer
1-5
Options
1. Trays 3-5, (2500-Sheet High-Capacity Feeder)
2. Finisher Door (Finisher with booklet maker)
3. Finisher Upper Output Tray
4. Finisher Stacker Output Tray
5. Cover 5 (Finisher Door 5)
6. Finisher Booklet Output Tray
7. Door B
8. Door C
9. Trays 3-5 (1500-Sheet High-Capacity Feeder)
10. Horizontal transport (top output tray with finisher installed)
11. Punch Waste Box
12. Staple unit
13. Saddle staple unit
14. Booklet drawer
