Xerox WorkCentre 4250 Installation Guide

Installation
Xerox Common Access Card
Common Access Card Installation Guide
12
Software Enablement
Prior to installing the Common Access Card solution, the software requires enabling on your Xerox
device using CentreWare Internet Services. The Feature Enable Key and the instructions are provided in
your Enablement Kit. Follow the instructions provided in the Xerox Common Access Card Enablement
Guide to upgrade your device software and install the Feature Enable Key.
Once the Common Access Card software has been enabled, use the following instructions to configure
Common Access Card on your device using CentreWare Internet Services.
Configuring Common Access Card
Once the Common Access Card feature has been enabled on the device it can be configured using
CentreWare Internet Services.
Follow the instructions below to configure Common Access Card:
Note: Some of the steps shown may require the System Administration password for your device
to be entered.
1. Access CentreWare Internet Services.
a. Open the web browser from your Workstation.
b. In the URL field, enter http:// followed by the IP Address of the device. For example: If the IP
Address is 192.168.100.100, enter the following into the URL field: http://192.168.100.100.
c. Press Enter to view the Home page.
2. Access Properties.
a. Select the Properties tab.
b. If prompted, enter the Administrator User ID and Password. The default is admin and 1111.
c. Select the Login button.
3. Configure the Common Access Card software.
a. Select the Security link.
b. Select the Authentication link.
c. Select Authentication in the
Directory Tree.
d. In the Setup section, select
Require Network
Authentication.
e. In the Authentication Type
option select CAC/PIV (Common
Access Card/Personal Identity
Verification).
f. In the Timeout option enter the number of minutes the system waits before logging out the
user.

Xerox WorkCentre 4250 Specifications

General

Copier resize	25 - 400 %
Maximum number of copies	999 copies
Copy resolution (black text)	600 x 600 DPI
Copy speed (black, normal quality, A4)	45 cpm
Standard input capacity	600 sheets
Auto document feeder (ADF) input capacity	100 sheets
Power consumption (standby)	111 W
Power consumption (typical)	794 W
Maximum duty cycle	200000 pages per month
Print speed (black, normal quality, A4/US Letter)	- ppm
Drivers included	Yes
Type	Analog copier
Bundled software	Image Retriever, Nuance OmniPage, Nuance PaperPort
Sustainability certificates	ENERGY STAR
Storage temperature (T-T)	10 - 32 °C
Non-operating relative humidity (non-condensing)	20 - 80 %
Maximum resolution	- DPI
Maximum print size	215 x 355 mm
Standard media sizes	99 x 147 mm - 216 x 356 mm
Compatible operating systems	HP-UX 10.2, IBM AIX 4.2, Linux, Mandrake 9.2-10.1, Red Hat 9, SUSE 9, Windows 2003 Server, Windows Vista, Windows XP, Windows XP Pro HP-UX 10.2, IBM AIX 4.2, Linux, Mandrake 9.2-10.1, Red Hat 9, SUSE 9, Windows 2003 Server, Windows Vista, Windows XP, Windows XP Pro
Standard interfaces	USB 2.0
Dimensions (WxDxH)	622 x 483 x 648 mm
Certification	FCC Part 15, Class A, FCC Part 68, UL Listed 60950-1/CSA 60950-1-03, CE 2006/95/EC, 2004/108/EC and 1999/5/ EC, Section 508 ADA, Cerner Tested and Certified 2004/108/EC and 1999 / 5 / EC, Section 508 ADA
