8-3
EXPLODED VIEW & PA RTS LIST
Service Manual
WorkCentre PE16 June 2003
Main Assembly Parts List
No. Description Part Number Q’ty Remark
0 WorkCentre PE16
1 ELA HOU-UNIT SCAN 500 N 00105 1
1-1 COVER-LCD WINDOW * 1 Not Spared
1-2 ELA HOU-ADF 101 N 01337 1
1-3 AS-ELA HOU-OPE(XEROX) 101 N 01338 1
1-4 ELA HOU-PLATEN 101 N 01339 1
2 ELA HOU-UNIT FRAME_110V 001 N 00407 1 110V
ELA HOU-UNIT FRAME_220V 001 N 00408 1 220V
3 ELA UNIT-RX DRIVE 126 N 00211 1
4 UNIT-LSU 122 N 00228 1
5 CBF HARNESS-LSU 152 N 02010 1
7 SMPS-SMPS(V1)+HVPS 105 N 02005 1 110V
SMPS-SMPS(V2)+HVPS 105 N 02006 1 220V
8 PBA MAIN-MAIN 140 N 62743 1
9 MEA UNIT-COVER MIDDLE 101 N 01334 1
10 MEA UNIT-COVER FRONT(XEROX) 101 N 01335 1
10-1 ADJUST-M-MANUAL_R * 1 Not Spared
10-2 ADJUST RACK-M-MANUAL * 2 Not Spared
10-3 COVER-M_FRONT(ROCKY) * 1 Not Spared
10-4 ADJUST-M-MANUAL_L * 1 Not Spared
10-5 GEAR-RACK_PINION * 1 Not Spared
11 MEA UNIT-CASSETTE, USA 050 N 00427 1
12 ELA HOU-COVER SIDE L 101 N 01336 1
12-1 COVER-M-SIDE L * 1 Not Spared
12-2 SPEAKER * 1 Not Spared
12-3 SCREW-TAPTITE * 2 Not Spared
13 COVER-M-SIDE R 002 N 02191 1
14 MEA UNIT-COVER REAR 002 N 02192 1
14-1 COVER-M-REAR * 1 Not Spared
14-2 COVER-M-FACE UP * 1 Not Spared
15 FAN-DC 127 N 01453 1
16 CBF HARNESS-MOTOR 152 N 02009 1
17 MEA ETC-TR 022 N 01606 1
17-1 ROLLER-TRANSFER ROLLER 022 N 02017 1
17-2 GEAR-TRANSFER * 1 Not Spared
17-3 PPR-SPACER_TR * 1 Not Spared
To Next Page
