Xerox WorkCentre PE16 Service Manual

8-4
EXPLODED VIEW & PA RTS LIST
Service Manual
June 2003 WorkCentre PE16
Main Assembly Parts List(cont.)
No. Description Part Number Q’ty Remark
18 CBF SIGNAL-LIU 140 N 62744 1
19 PBA-LIU_USA/CANADA 140 N 62758 1
PBA-LIU_WESTERN EUROPE 140 N 62745 1
PBA-LIU_RUSSIA 140 N 62759 1
PBA-LIU_SOUTH AFRICA 140 N 62760 1
20 ELA-TONER UNIT * 1 Not Spared
21 PLATE-P-CHANNEL 015 N 00495 1
22 PBA SUB-CONN 140 N 62750 1
23 CBF HARNESS-ENGINE 152 N 02012 1
24 “BRACKET-P-INLET, ROCKY” 030 N 00654 1
25 MEA UNIT-SHIELD ENGINE 055 N 00277 1
25-1 “SHIELD-ENGINE, ROCKY” * 1 Not Spared
25-2 SUPPORTER * 2 Not Spared
26 CBF HARNESS-SCAN 152 N 11462 1
27 SUPPORTER 030 N 00655 1
28 CBF-HARNESS-DUPLEX GND 152 N 11463 1
29 SHEET-OVERLAY(XEROX) 002 N 02194 1
