8-8
EXPLODED VIEW & PA RTS LIST
Service Manual
June 2003 WorkCentre PE16
ADF Assembly Parts List
No. Description Part Number Q’ty Remark
0 ELA HOU-ADF 101 N 01337 1
1 MEA UNIT-ADF UPPER 500 N 00106 1
1-1 COVER-M-ADF UPPER 002 N 02195 1
1-2 ROLLER-M-ADF IDLE 022 N 02012 1
1-3 MEA UNIT-HOLDER ADF 500 N 00107 1
1-3-1 RMO-ADF RUBBER 019 N 00566 1
1-3-2 HOLDER-M-ADF * 1 Not Spared
1-3-3 SPRING ETC-PAD * 1 Not Spared
1-3-4 SHEET-ADF HOLDER * 1 Not Spared
2 ELA HOU-ADF LOWER 101 N 01340 1
2-1 COVER-M-ADF LOWER * 1 Not Spared
2-2 PBA SUB-ADF * 1 Not Spared
2-3 GROUND-P-ADF * 1 Not Spared
2-4 SHAFT-M-FEED GEAR 38 * 1 Not Spared
2-5 ROLLER-DRIVE * 1 Not Spared
2-6 PMO-ACTUATOR DOC SENSOR * 1 Not Spared
2-7 PMO-ACTUATOR REGI SENSOR * 1 Not Spared
2-8 PMO-ACTUATOR SCAN SENSOR * 1 Not Spared
2-9 SPRING ETC-TORSION DOC (CC2-F) * 3 Not Spared
2-10 IPR-GROUND_ROLLER * 1 Not Spared
2-11 SHAFT-IDLE FEED * 2 Not Spared
2-12 ROLLER-EXIT * 1 Not Spared
2-13 MEC-BRUSH ANTISTATIC * 1 Not Spared
2-14 SHEET-WHITE BAR * 1 Not Spared
2-15 PMO-BUSH * 4 Not Spared
2-16 CBF HARNESS-ADR * 1 Not Spared
2-17 GEAR-AGITATOR-2 * 1 Not Spared
2-18 RING-C * 1 Not Spared
2-19 GUIDE-STACKER SUB * 2 Not Spared
2-S SCREW-TAPTITE * 9 Not Spared
3 ELA HOU-ADF MOTOR 101 N 01341 1
3-1 BRACKET-GEAR * 1 Not Spared
3-2 MOTOR BLOWER-ADF * 1 Not Spared
3-3 GEAR-CLUTCH 29 * 1 Not Spared
3-4 PMO-WHITE CLUTCH SUB 29 * 1 Not Spared
3-5 GEAR-CLUTCH 39 * 1 Not Spared
3-6 RING-C * 1 Not Spared
3-7 GEAR-IDLE 35 ADF * 3 Not Spared
3-8 GEAR-40/21 ADF * 3 Not Spared
To Next Page
