8-9
EXPLODED VIEW & PA RTS LIST
Service Manual
WorkCentre PE16 June 2003
ADF Assembly Parts List(cont.)
No. Description Part Number Q’ty Remark
3-9 GEAR-SWING 31/20 ADF * 1 Not Spared
3-10 LINK-M-SWING ADF * 1 Not Spared
3-11 GEAR-58/25 ADF * 1 Not Spared
3-12 IMPELLER-ADF * 1 Not Spared
3-13 GEAR-REMOVE ADF * 1 Not Spared
3-14 WASHER-PLAIN * 2 Not Spared
3-15 IPR-WASHER WAVE * 1 Not Spared
3-16 WASHER-PLAIN * 3 Not Spared
3-17 CBF HARNESS-MOTOR GND * 1 Not Spared
3-18 RING-E * 6 Not Spared
3-19 SCREW-TAPTITE * 3 Not Spared
3-20 SPRING ETC PAD * 1 Not Spared
4 MEA UNIT-COVER PLATEN * 1 Not Spared
4-1 COVER-M-PLATEN(4IN1) 002 N 02196 1
4-2 SHEET-WHITE SPONGE * 1 Not Spared
4-3 MEA-TX STACKER(XEROX) * 1 Not Spared
4-3-1 PMO-TX STACKER(XEROX) 038 N 00405 1
4-3-2 PMO-DOC GUIDE(L) 038 N 00406 1
4-3-3 GEAR-PINION 007 N 01210 1
4-3-4 PMO-DOC GUIDE(R) 038 N 00410 1
4-3-5 IPR-WASHER SPRING CU 028 N 00321 2
4-4 SPRING ETC-FEED * 6 Not Spared
4-5 PMO-ROLL PINCH 022 N 02014 2
4-6 SHAFT-STACKER 006 N 01217 2
4-7 MEA UNIT-HINGE 003 N 00888 2
4-8 RPR-ROLLER EXIT IDLE 022 N 02019 2
4-9 ICT-SHAFT PINCH 006 N 01218 1
4-S SCREW-TAPTITE * 14 Not Spared
5 MEA UNIT-COVER OPEN 002 N 02197 1
5-1 COVER-M-OPEN * 1 Not Spared
5-2 PMO-GUIDE PAPER * 2 Not Spared
6 MEA UNIT-PICKUP 130 N 01270 1
6-1 PMO-BUSHING WHITE * 1 Not Spared
6-2 GEAR-ADF 38 * 1 Not Spared
6-3 RING-C * 1 Not Spared
6-4 ADF-ROLLER 022 N 02018 1
To Next Page
