8-13
EXPLODED VIEW & PA RTS LIST
Service Manual
WorkCentre PE16 June 2003
Scanner Assembly Parts List
No. Description Part Number Q’ty Remark
0 ELA HOU-PLATEN 101 N 01339 1
1 MEA UNIT-SCAN UPPER * 1 Not Spared
1-1 COVER-M-SCAN UPPER 002 N 02199 1
1-2 GLASS-SCAN 118 N 00500 1
1-3 MEA UNIT-SCAN DUMMY 500 N 00108 1
1-3-1 COVER-M-SCAN DUMMY(4IN1) * 1 Not Spared
1-3-2 MCT-GLASS ADF * 1 Not Spared
1-3-3 TAPE-DOUBLE FACE * 1 Not Spared
1-3-4 LABEL(P)-SHADING * 1 Not Spared
2 ELA HOU-SCAN LOWER 101 N 01342 1
2-1 COVER-M-SCAN LOWER * 1 Not Spared
2-2 ELA HOU-CCD MODULE 101 N 01343 1
2-3 CBF SIGNAL-CCD FFC 130 N 01271 1
2-4 ELA UNIT-CORE * 2 Not Spared
2-5 ICT-SHAFT CCD 130 N 01272 1
2-6 PMO-HOLDER BELT * 1 Not Spared
2-7 PMO-PULLEY * 1 Not Spared
2-8 PMO-HOLDER BELT * 1 Not Spared
2-9 SPRING ETC-BELT * 1 Not Spared
2-10 SPRING-CS * 1 Not Spared
2-11 PMO-LEVER SENSOR 130 N 01273 1
2-12 PHOTO-INTERRUPTER 130 N 01274 1
2-13 CBF HARNESS-OPE/FLAT_COVER 101 N 01344 1
2-14 BELT-TIMING GEAR 109 N 00542 1
2-15 ELA HOU-SCAN MOTOR 101 N 01345 1
2-15-1 BRACKET-M-SCAN MOTOR * 1 Not Spared
2-15-2 MOTOR STEP-SCAN * 1 Not Spared
2-15-3 GEAR-REDUCTION * 1 Not Spared
2-15-4 GEAR-IDLE * 1 Not Spared
2-15-5 GEAR-TIMING * 1 Not Spared
2-15-6 PMO-HOLDER BELT * 1 Not Spared
2-15-7 RING-E * 1 Not Spared
2-16 DUMPER-CCD * 2 Not Spared
To Next Page
