Precautions
Service Manual
July 2003 WorkCentre PE16
Servicing Electrical Components
Before starting any service procedure, switch off the product power and unplug the
power cord from the wall outlet. If you must service the unit with power applied,
be aware of the potential for electrical shock.
Turning the power off by using the On/Off switch does not completely de-energize
the unit. You must also disconnect the unit's power cord from the AC outlet.
Position the power cord so that it is easily accessible during servicing.
Do not touch any electrical component unless you are instructed to do so by a
service procedure.
Servicing Mechanical Components
When servicing mechanical components within the unit, manually rotate drive
assemblies, rollers, and gears.
Do not try to manually rotate or manually stop the drive assemblies while any
unit drive motor is running.
Servicing Fuser Components
This product uses heat to fuse the toner image to media. The Fuser Assembly is
VERY HOT. Turn the unit power off and wait at least 5 minutes for the Fuser
to cool before you attempt to service the Fuser Assembly or adjacent components.
