Category Description
Installation space ● Requirements for cabinet installation:
Cabinet compliant with the International
Electrotechnical Commission (IEC) 297 standard
– Cabinet width: 482.6 mm (19.00 in.)
– Cabinet depth ≥ 1000 mm (39.37 in.)
● Requirements for guide rail installation:
– L-shaped guide rails: apply only to xFusion
cabinets.
– Static rail kit: applies to cabinets with a distance of
543.5 mm to 848.5 mm (21.40 in. to 33.41 in.)
between the front and rear mounting bars.
– Ball bearing rail kit: applies to cabinets with a
distance of 609 mm to 950 mm (23.98 in. to 37.40
in.) between the front and rear mounting bars.
Weight in full
configuration
● Net weight:
– Maximum weight for server with 8 x 2.5" front
drives: 22.5 kg (49.60 lb)
– Maximum weight for server with 12 x 2.5" front
drives: 23.5 kg (51.80 lb)
– Maximum weight for server with 12 x 3.5" front
drives: 35.5 kg (78.26 lb)
– Maximum weight for server with 24 x 2.5" front
drives: 25.5 kg (56.22 lb)
– Maximum weight for server with 25 x 2.5" front
drives: 25.5 kg (56.22 lb)
● Packaging materials: 5 kg (11.03 lb)
Power consumption
The power consumption parameters vary with hardware
configurations (including the configurations complying
with EU ErP). Use the Power Calculator to obtain
specific information.
FusionServer 2288H V7 Server
Technical White Paper 6 Product Specifications
Issue 02 (2023-05-25) Copyright © xFusion Digital Technologies Co., Ltd. 117
