5.2.2 Indicators and Buttons
Indicator Positions
● Server with a drive module or PCIe riser module on the rear panel
Figure 5-18 Indicators on the rear panel
1
Data transmission status
indicator for the
management network
port
2 Connection status
indicator for the
management network
port
3 Serial port indicator
NOTE
Reserved and unavailable
currently
4 UID indicator
5 PSU indicator - -
● 4-GPU model
Figure 5-19 Indicators on the rear panel
1
Data transmission status
indicator for the
management network
port
2 Connection status
indicator for the
management network
port
3 Serial port indicator
NOTE
Reserved and unavailable
currently
4 UID indicator
