Xilinx Kintex-7 FPGA KC705 User Manual

KC705 Getting Started Guide www.xilinx.com 21
UG883 (v4.0.1) May 28, 2014
Advanced Bring-up Using the Base Targeted Reference Design
Hardware Test Setup Requirements
These are the prerequisites for testing the design in hardware:
• KC705 Evaluation board with the Kintex-7 FPGA XC7K325T-2FFG900C device
• Design files provided as a zipped collection under the Docs & Designs tab at
www.xilinx.com/kc705
include:
• Design source files
• Device driver files
• Board design files
• Documentation
• Vivado Design Suite
• ISE Programming tools or LabTools
•Micro USB cable
• 4-pin to 6-pin PCIe adapter cable
• Fedora 16 Live DVD [Ref 6]
• PC with PCIe v2.0 slot. For a complete list of machines tested, and all known issues,
refer to the Kintex-7 FPGA Base Targeted Reference Design Release Notes and Known
Issues Master Answer Record (http://www.xilinx.com/support/answers/
45679.htm). This PC could also have Fedora Core 16 Linux OS installed on it.
TRD Demonstration Setup
This section describes hardware setup and use of the application GUI to help the user get
started quickly with the design in hardware. It provides a step-by-step explanation of
hardware bring-up, and describes using the application GUI.
When following the demonstration setup steps for the Kintex-7 FPGA Base TRD, if the
behavior is not as described, refer to the known issues at www.xilinx.com/support/
answers/45679.htm.
Send Feedback

Xilinx Kintex-7 FPGA KC705 Specifications

General

FPGA Speed Grade	-2
FPGA Package	FFG900
Logic Cells	326, 080
DSP Slices	840
Clock Management Tiles	10
Transceivers	16
DDR3 Memory	1GB
Flash Memory	128MB
Clock	200 MHz oscillator
Form Factor	ATX
Ethernet	10/100/1000
Expansion Connectors	FMC
USB	USB-UART
