Xilinx Kria K26 SOM User Manual

Table 1: SOM240 Signal Naming Conventions
Signal Description
Module (M) The SOM, in this case the K26 SOM
Carrier card (C) The board that the SOM is plugged into is called the carrier card
C2M Signal names with C2M indicate that the signal is driven by the carrier card and received by
the SOM
M2C Signal names with M2C indicate that the signal is driven by the SOM and received by the
carrier card
_P The postfix _P on differential signal pairs indicates the positive component of a differential
signal
_N The postfix _N on differential signal pairs indicates the negative component of a differential
signal
_L The postfix _L on a single-ended signal indicates an active-Low signal. This is used for the
connector pinouts only. The postfix _B is also used to indicate an active-Low signal.
Table 2: Legend for Connector Pinouts
Example SOM240 Connector Function
GND Both SOM240_1 and SOM240_2 Ground pins
VCC_SOM Both SOM240_1 and SOM240_2 Power connection pins
MIO35 SOM240_1 MIO 501 bank pins
MIO58 SOM240_1 MIO 502 bank pins
JTAG_TMS_C2M SOM240_1 Configuration and control pins
GTR_DP1_M2C_P SOM240_1 PS-GTR transceiver pins
HPA04_P SOM240_1 HPA pins
HDA00_CC SOM240_1 HDA pins
HPB15_CC_P SOM240_2 HPB pins
HPC07_P SOM240_2 HPC pins
HDB12 SOM240_2 HDB pins
HDC00_CC SOM240_2 HDC pins
GTH_DP2_C2M_P SOM240_2 GTH transceiver pins
SOM240_1 Connector Pinout
The SOM240_1 connector provides access to two MIO banks (MIO501, MIO502), HPIO bank 66
(HPA), HDIO bank 45 (HDA), and the PS-GTR transceivers (MIO505). It also provides sideband
signals for conguraon and operaon of the board.
