Xilinx VC707 User Manual

VC707 Evaluation Board www.xilinx.com 19
UG885 (v1.4) May 12, 2014
Feature Descriptions
AF30 FLASH_A3 D1 A4
AK29 FLASH_A4 D2 A5
AK28 FLASH_A5 A2 A6
AG29 FLASH_A6 C2 A7
AK30 FLASH_A7 A3 A8
AJ30 FLASH_A8 B3 A9
AH30 FLASH_A9 C3 A10
AH29 FLASH_A10 D3 A11
AL30 FLASH_A11 C4 A12
AL29 FLASH_A12 A5 A13
AN33 FLASH_A13 B5 A14
AM33 FLASH_A14 C5 A15
AM32 FLASH_A15 D7 A16
AV41 FLASH_A16 D8 A17
AU41 FLASH_A17 A7 A18
BA42 FLASH_A18 B7 A19
AU42 FLASH_A19 C7 A20
AT41 FLASH_A20 C8 A21
BA39 FLASH_A21 A8 A22
BA39 FLASH_A22 G1 A23
BB39 FLASH_A23 H8 A24
AW42 FLASH_A24 B6 A25
AW41 FLASH_A25 B8 A26
NA NC H1 A27
AM36 FLASH_D0 F2 DQ0
AN36 FLASH_D1 E2 DQ1
AJ36 FLASH_D2 G3 DQ2
AJ37 FLASH_D3 E4 DQ3
AK37 FLASH_D4 E5 DQ4
AL37 FLASH_D5 G5 DQ5
AN35 FLASH_D6 G6 DQ6
AP35 FLASH_D7 H7 DQ7
Table 1-5: BPI Flash Memory Connections to the FPGA (Cont’d)
FPGA (U1) Pin Net Name
BPI Flash Memory (U3)
Pin Number Pin Name
