Chapter 1: VC707 Evaluation Board Features
For more information on the GTX transceivers, see 7 Series FPGAs GTX/GTH Transceivers
User Guide (UG476) [Ref 6].
MGT_BANK_115 GTXE2_CHANNEL_X1Y8 PCIe3
GTXE2_CHANNEL_X1Y9 PCIe2
GTXE2_CHANNEL_X1Y10 PCIe1
GTXE2_CHANNEL_X1Y11 PCIe0
MGTREFCLK0 NC
MGTREFCLK1 PCIe_CLK
MGT_BANK_116 GTXE2_CHANNEL_X1Y12 FMC2 HPC DP4
GTXE2_CHANNEL_X1Y13 FMC2 HPC DP5
GTXE2_CHANNEL_X1Y14 FMC2 HPC DP6
GTXE2_CHANNEL_X1Y15 FMC2 HPC DP7
MGTREFCLK0 FMC2 HPC GBT_CLK1
MGTREFCLK1 NC
MGT_BANK_117 GTXE2_CHANNEL_X1Y16 FMC2 HPC DP0
GTXE2_CHANNEL_X1Y17 FMC2 HPC DP1
GTXE2_CHANNEL_X1Y18 FMC2 HPC DP2
GTXE2_CHANNEL_X1Y19 FMC2 HPC DP3
MGTREFCLK0 FMC2 HPC GBT_CLK0
MGTREFCLK1 NC
MGT_BANK_118 GTXE2_CHANNEL_X1Y20 FMC1 HPC DP4
GTXE2_CHANNEL_X1Y21 FMC1 HPC DP5
GTXE2_CHANNEL_X1Y22 FMC1 HPC DP6
GTXE2_CHANNEL_X1Y23 FMC1 HPC DP7
MGTREFCLK0 FMC1 HPC GBT_CLK1
MGTREFCLK1 NC
MGT_BANK_119 GTXE2_CHANNEL_X1Y24 FMC1 HPC DP0
GTXE2_CHANNEL_X1Y25 FMC1 HPC DP1
GTXE2_CHANNEL_X1Y26 FMC1 HPC DP3
GTXE2_CHANNEL_X1Y27 FMC1 HPC DP4
MGTREFCLK0 FMC1 HPC GBT_CLK0
MGTREFCLK1 NC
Table 1-11: GTX Interface Connections for FPGA U1 (Cont’d)
Transceiver Bank Net Name Connections
