Xilinx VC707 User Manual

VC707 Evaluation Board www.xilinx.com 67
UG885 (v1.4) May 12, 2014
Feature Descriptions
E22 FMC2_HPC_HB03_N AU16 F22 FMC2_HPC_HB02_P AV16
E24 FMC2_HPC_HB05_P BA17 F23 FMC2_HPC_HB02_N AW16
E25 FMC2_HPC_HB05_N BB17 F25 FMC2_HPC_HB04_P AU18
E27 FMC2_HPC_HB09_P AV20 F26 FMC2_HPC_HB04_N AV18
E28 FMC2_HPC_HB09_N AW20 F28 FMC2_HPC_HB08_P AY20
E30 FMC2_HPC_HB13_P AT20 F29 FMC2_HPC_HB08_N BA20
E31 FMC2_HPC_HB13_N AT19 F31 FMC2_HPC_HB12_P AV19
E33 FMC2_HPC_HB19_P AP18 F32 FMC2_HPC_HB12_N AT20
E34 FMC2_HPC_HB19_N AP17 F34 FMC2_HPC_HB16_P AR18
E36 FMC2_HPC_HB21_P AN19 F35 FMC2_HPC_HB16_N AR17
E37 FMC2_HPC_HB21_N AN18 F37 FMC2_HPC_HB20_P AK17
E39 VADJ F38 FMC2_HPC_HB20_N AL17
F40 VADJ
G2 FMC2_HPC_CLK1_M2C_P U39 H1 NC
G3 FMC2_HPC_CLK1_M2C_N T39 H2 FMC2_HPC_PRSNT_M2C_B AG32
G6 FMC2_HPC_LA00_CC_P AD40 H4 FMC2_HPC_CLK0_M2C_P AF39
G7 FMC2_HPC_LA00_CC_N AD41 H5 FMC2_HPC_CLK0_M2C_N AF40
G9 FMC2_HPC_LA03_P AJ42 H7 FMC2_HPC_LA02_P AK39
G10 FMC2_HPC_LA03_N AK42 H8 FMC2_HPC_LA02_N AL39
G12 FMC2_HPC_LA08_P AD42 H10 FMC2_HPC_LA04_P AL41
G13 FMC2_HPC_LA08_N AE42 H11 FMC2_HPC_LA04_N AL42
G15 FMC2_HPC_LA12_P Y39 H13 FMC2_HPC_LA07_P AC40
G16 FMC2_HPC_LA12_N AA39 H14 FMC2_HPC_LA07_N AC41
G18 FMC2_HPC_LA16_P AJ40 H16 FMC2_HPC_LA11_P Y42
G19 FMC2_HPC_LA16_N AJ41 H17 FMC2_HPC_LA11_N AA42
G21 FMC2_HPC_LA20_P V33 H19 FMC2_HPC_LA15_P AC38
G22 FMC2_HPC_LA20_N V34 H20 FMC2_HPC_LA15_N AC39
G24 FMC2_HPC_LA22_P W32 H22 FMC2_HPC_LA19_P U32
G25 FMC2_HPC_LA22_N W33 H23 FMC2_HPC_LA19_N U33
G27 FMC2_HPC_LA25_P R33 H25 FMC2_HPC_LA21_P P35
G28 FMC2_HPC_LA25_N R34 H26 FMC2_HPC_LA21_N P36
G30 FMC2_HPC_LA29_P W36 H28 FMC2_HPC_LA24_P U34
Table 1-28: J37 VITA 57.1 FMC 2 HPC Connections (Cont’d)
J37 FMC 2
HPC Pin
Schematic Net Name
U1 FPGA
Pin
J37 FMC 2
HPC Pin
Schematic Net Name U1 FPGA Pin
