Xilinx VC707 User Manual

66 www.xilinx.com VC707 Evaluation Board
UG885 (v1.4) May 12, 2014
Chapter 1: VC707 Evaluation Board Features
C18 FMC2_HPC_LA14_P AB38 D15 FMC2_HPC_LA09_N AK38
C19 FMC2_HPC_LA14_N AB39 D17 FMC2_HPC_LA13_P W40
C22 FMC2_HPC_LA18_CC_P U36 D18 FMC2_HPC_LA13_N Y40
C23 FMC2_HPC_LA18_CC_N T37 D20 FMC2_HPC_LA17_CC_P U37
C26 FMC2_HPC_LA27_P P32 D21 FMC2_HPC_LA17_CC_N U38
C27 FMC2_HPC_LA27_N P33 D23 FMC2_HPC_LA23_P R38
C30 FMC2_HPC_IIC_SCL U52.6 D24 FMC2_HPC_LA23_N R39
C31 FMC2_HPC_IIC_SDA U52.5 D26 FMC2_HPC_LA26_P N33
C34 GND D27 FMC2_HPC_LA26_N N34
C35 VCC12_P D29 FMC2_HPC_TCK_BUF U19.13
C37 VCC12_P D30 FMC1_TDO_FMC2_TDI U27.2
C39 VCC3V3 D31 FMC2_TDO_FPGA_TDI U46.3
D32 VCC3V3
D33 FMC2_HPC_TMS_BUF U19.16
D34 NC
D35 GND
D36 VCC3V3
D38 VCC3V3
D40 VCC3V3
E2 FMC2_HPC_HA01_CC_P AD32 F1 FMC2_HPC_PG_M2C AF29
E3 FMC2_HPC_HA01_CC_N AD33 F4 FMC2_HPC_HA00_CC_P AB33
E6 FMC2_HPC_HA05_P Y32 F5 FMC2_HPC_HA00_CC_N AC33
E7 FMC2_HPC_HA05_N Y33 F7 FMC2_HPC_HA04_P AB29
E9 FMC2_HPC_HA09_P AE29 F8 FMC2_HPC_HA04_N AC29
E10 FMC2_HPC_HA09_N AE30 F10 FMC2_HPC_HA08_P AA31
E12 FMC2_HPC_HA13_P AE32 F11 FMC2_HPC_HA08_N AA32
E13 FMC2_HPC_HA13_N AE33 F13 FMC2_HPC_HA12_P AF34
E15 FMC2_HPC_HA16_P AG36 F14 FMC2_HPC_HA12_N AG34
E16 FMC2_HPC_HA16_N AH36 F16 FMC2_HPC_HA15_P AE37
E18 FMC2_HPC_HA20_P AD36 F17 FMC2_HPC_HA15_N AF37
E19 FMC2_HPC_HA20_N AD37 F19 FMC2_HPC_HA19_P AC35
E21 FMC2_HPC_HB03_P AT16 F20 FMC2_HPC_HA19_N AC36
Table 1-28: J37 VITA 57.1 FMC 2 HPC Connections (Cont’d)
J37 FMC 2
HPC Pin
Schematic Net Name
U1 FPGA
Pin
J37 FMC 2
HPC Pin
Schematic Net Name U1 FPGA Pin
