Xilinx VC707 User Manual

VC707 Evaluation Board www.xilinx.com 65
UG885 (v1.4) May 12, 2014
Feature Descriptions
Table 1-28 lists the connections between the FMC2 HPC J37 connector and the FPGA U1.
Note:
The FMC2 HPC HB00-HB21 pair connections are not available with the
XC7VX485T-2FFG1761C FPGA installed on the VC707. Refer to the Virtex-7 FPGA VC707
Evaluation Kit Master Answer Record in Appendix F: References for more information.
Table 1-28: J37 VITA 57.1 FMC 2 HPC Connections
J37 FMC 2
HPC Pin
Schematic Net Name
U1 FPGA
Pin
J37 FMC 2
HPC Pin
Schematic Net Name U1 FPGA Pin
A2 FMC2_HPC_DP1_M2C_P N6 B1 NC
A3 FMC2_HPC_DP1_M2C_N N5 B4 NC
A6 FMC2_HPC_DP2_M2C_P L6 B5 NC
A7 FMC2_HPC_DP2_M2C_N L5 B8 NC
A10 FMC2_HPC_DP3_M2C_P J6 B9 NC
A11 FMC2_HPC_DP3_M2C_N J5 B12 FMC2_HPC_DP7_M2C_P P4
A14 FMC2_HPC_DP4_M2C_P W6 B13 FMC2_HPC_DP7_M2C_N P3
A15 FMC2_HPC_DP4_M2C_N W5 B16 FMC2_HPC_DP6_M2C_P U6
A18 FMC2_HPC_DP5_M2C_P V4 B17 FMC2_HPC_DP6_M2C_N U5
A19 FMC2_HPC_DP5_M2C_N V3 B20 FMC2_HPC_GBTCLK1_M2C_P T8
A22 FMC2_HPC_DP1_C2M_P M4 B21 FMC2_HPC_GBTCLK1_M2C_N T7
A23 FMC2_HPC_DP1_C2M_N M3 B24 NC
A26 FMC2_HPC_DP2_C2M_P L2 B25 NC
A27 FMC2_HPC_DP2_C2M_N L1 B28 NC
A30 FMC2_HPC_DP3_C2M_P K4 B29 NC
A31 FMC2_HPC_DP3_C2M_N K3 B32 FMC2_HPC_DP7_C2M_P R6
A34 FMC2_HPC_DP4_C2M_P U2 B33 FMC2_HPC_DP7_C2M_N R5
A35 FMC2_HPC_DP4_C2M_N U1 B36 FMC2_HPC_DP6_C2M_P R2
A38 FMC2_HPC_DP5_C2M_P T4 B37 FMC2_HPC_DP6_C2M_N R1
A39 FMC2_HPC_DP5_C2M_N T3 B40 NC
C2 FMC2_HPC_DP0_C2M_P N2 D1 PWRCTL1_VCC4B_PG AL32
C3 FMC2_HPC_DP0_C2M_N N1 D4 FMC2_HPC_GBTCLK0_M2C_P K8
C6 FMC2_HPC_DP0_M2C_P P8 D5 FMC2_HPC_GBTCLK0_M2C_N K7
C7 FMC2_HPC_DP0_M2C_N P7 D8 FMC2_HPC_LA01_CC_P AF41
C10 FMC2_HPC_LA06_P AD38 D9 FMC2_HPC_LA01_CC_N AG41
C11 FMC2_HPC_LA06_N AE38 D11 FMC2_HPC_LA05_P AF42
C14 FMC2_HPC_LA10_P AB41 D12 FMC2_HPC_LA05_N AG42
C15 FMC2_HPC_LA10_N AB42 D14 FMC2_HPC_LA09_P AJ38
