Xilinx VC707 User Manual

64 www.xilinx.com VC707 Evaluation Board
UG885 (v1.4) May 12, 2014
Chapter 1: VC707 Evaluation Board Features
J2 NC K1 NC
J3 NC K4 NC
J6 FMC1_HPC_HA03_P H33 K5 NC
J7 FMC1_HPC_HA03_N G33 K7 FMC1_HPC_HA02_P E33
J9 FMC1_HPC_HA07_P C38 K8 FMC1_HPC_HA02_N D33
J10 FMC1_HPC_HA07_N C39 K10 FMC1_HPC_HA06_P G36
J12 FMC1_HPC_HA11_P J37 K11 FMC1_HPC_HA06_N G37
J13 FMC1_HPC_HA11_N J38 K13 FMC1_HPC_HA10_P H38
J15 FMC1_HPC_HA14_P E37 K14 FMC1_HPC_HA10_N G38
J16 FMC1_HPC_HA14_N E38 K16 FMC1_HPC_HA17_CC_P C35
J18 FMC1_HPC_HA18_P F39 K17 FMC1_HPC_HA17_CC_N C36
J19 FMC1_HPC_HA18_N E39 K19 FMC1_HPC_HA21_P D37
J21 FMC1_HPC_HA22_P F36 K20 FMC1_HPC_HA21_N D38
J22 FMC1_HPC_HA22_N F37 K22 FMC1_HPC_HA23_P A35
J24 FMC1_HPC_HB01_P H28 K23 FMC1_HPC_HA23_N A36
J25 FMC1_HPC_HB01_N H29 K25 FMC1_HPC_HB00_CC_P J25
J27 FMC1_HPC_HB07_P G26 K26 FMC1_HPC_HB00_CC_N J26
J28 FMC1_HPC_HB07_N G27 K28 FMC1_HPC_HB06_CC_P K23
J30 FMC1_HPC_HB11_P K22 K29 FMC1_HPC_HB06_CC_N J23
J31 FMC1_HPC_HB11_N J22 K31 FMC1_HPC_HB10_P M22
J33 FMC1_HPC_HB15_P M21 K32 FMC1_HPC_HB10_N L22
J34 FMC1_HPC_HB15_N L21 K34 FMC1_HPC_HB14_P J21
J36 FMC1_HPC_HB18_P G21 K35 FMC1_HPC_HB14_N H21
J37 FMC1_HPC_HB18_N G22 K37 FMC1_HPC_HB17_CC_P M24
K38 FMC1_HPC_HB17_CC_N L24
J39 FMC1_VIO_B_M2C BANK 36
VCCO
K40 FMC1_VIO_B_M2C BANK 36
VCCO
Table 1-27: J35 VITA 57.1 FMC 1 HPC Connections (Cont’d)
J35
FMC 1
HPC Pin
Schematic Net Name
U1 FPGA
Pin
J35
FMC 1
HPC Pin
Schematic Net Name
U1 FPGA
Pin
