Xilinx VC707 User Manual

VC707 Evaluation Board www.xilinx.com 63
UG885 (v1.4) May 12, 2014
Feature Descriptions
G2 FMC1_HPC_CLK1_M2C_P N30 H1 NC
G3 FMC1_HPC_CLK1_M2C_N M31 H2 FMC1_HPC_PRSNT_M2C_B AM31
G6 FMC1_HPC_LA00_CC_P K39 H4 FMC1_HPC_CLK0_M2C_P L39
G7 FMC1_HPC_LA00_CC_N K40 H5 FMC1_HPC_CLK0_M2C_N L40
G9 FMC1_HPC_LA03_P M42 H7 FMC1_HPC_LA02_P P41
G10 FMC1_HPC_LA03_N L42 H8 FMC1_HPC_LA02_N N41
G12 FMC1_HPC_LA08_P M37 H10 FMC1_HPC_LA04_P H40
G13 FMC1_HPC_LA08_N M38 H11 FMC1_HPC_LA04_N H41
G15 FMC1_HPC_LA12_P R40 H13 FMC1_HPC_LA07_P G41
G16 FMC1_HPC_LA12_N P40 H14 FMC1_HPC_LA07_N G42
G18 FMC1_HPC_LA16_P K37 H16 FMC1_HPC_LA11_P F40
G19 FMC1_HPC_LA16_N K38 H17 FMC1_HPC_LA11_N F41
G21 FMC1_HPC_LA20_P Y29 H19 FMC1_HPC_LA15_P M36
G22 FMC1_HPC_LA20_N Y30 H20 FMC1_HPC_LA15_N L37
G24 FMC1_HPC_LA22_P R28 H22 FMC1_HPC_LA19_P W30
G25 FMC1_HPC_LA22_N P28 H23 FMC1_HPC_LA19_N W31
G27 FMC1_HPC_LA25_P K29 H25 FMC1_HPC_LA21_P N28
G28 FMC1_HPC_LA25_N K30 H26 FMC1_HPC_LA21_N N29
G30 FMC1_HPC_LA29_P T29 H28 FMC1_HPC_LA24_P R30
G31 FMC1_HPC_LA29_N T30 H29 FMC1_HPC_LA24_N P31
G33 FMC1_HPC_LA31_P M28 H31 FMC1_HPC_LA28_P L29
G34 FMC1_HPC_LA31_N M29 H32 FMC1_HPC_LA28_N L30
G36 FMC1_HPC_LA33_P U31 H34 FMC1_HPC_LA30_P V30
G37 FMC1_HPC_LA33_N T31 H35 FMC1_HPC_LA30_N V31
G39 VADJ H37 FMC1_HPC_LA32_P V29
H38 FMC1_HPC_LA32_N U29
H40 VADJ
Table 1-27: J35 VITA 57.1 FMC 1 HPC Connections (Cont’d)
J35
FMC 1
HPC Pin
Schematic Net Name
U1 FPGA
Pin
J35
FMC 1
HPC Pin
Schematic Net Name
U1 FPGA
Pin
Send Feedback
