Xilinx VC707 User Manual

62 www.xilinx.com VC707 Evaluation Board
UG885 (v1.4) May 12, 2014
Chapter 1: VC707 Evaluation Board Features
E2 FMC1_HPC_HA01_CC_P D35 F1 FMC1_HPC_PG_M2C AN34
E3 FMC1_HPC_HA01_CC_N D36 F4 FMC1_HPC_HA00_CC_P E34
E6 FMC1_HPC_HA05_P G32 F5 FMC1_HPC_HA00_CC_N E35
E7 FMC1_HPC_HA05_N F32 F7 FMC1_HPC_HA04_P F34
E9 FMC1_HPC_HA09_P E32 F8 FMC1_HPC_HA04_N F35
E10 FMC1_HPC_HA09_N D32 F10 FMC1_HPC_HA08_P J36
E12 FMC1_HPC_HA13_P B36 F11 FMC1_HPC_HA08_N H36
E13 FMC1_HPC_HA13_N A37 F13 FMC1_HPC_HA12_P B37
E15 FMC1_HPC_HA16_P B39 F14 FMC1_HPC_HA12_N B38
E16 FMC1_HPC_HA16_N A39 F16 FMC1_HPC_HA15_P C33
E18 FMC1_HPC_HA20_P B34 F17 FMC1_HPC_HA15_N C34
E19 FMC1_HPC_HA20_N A34 F19 FMC1_HPC_HA19_P B32
E21 FMC1_HPC_HB03_P G28 F20 FMC1_HPC_HA19_N B33
E22 FMC1_HPC_HB03_N G29 F22 FMC1_HPC_HB02_P K28
E24 FMC1_HPC_HB05_P K27 F23 FMC1_HPC_HB02_N J28
E25 FMC1_HPC_HB05_N J27 F25 FMC1_HPC_HB04_P H24
E27 FMC1_HPC_HB09_P H23 F26 FMC1_HPC_HB04_N G24
E28 FMC1_HPC_HB09_N G23 F28 FMC1_HPC_HB08_P H25
E30 FMC1_HPC_HB13_P P25 F29 FMC1_HPC_HB08_N H26
E31 FMC1_HPC_HB13_N P26 F31 FMC1_HPC_HB12_P K24
E33 FMC1_HPC_HB19_P L25 F32 FMC1_HPC_HB12_N K25
E34 FMC1_HPC_HB19_N L26 F34 FMC1_HPC_HB16_P N25
E36 FMC1_HPC_HB21_P P22 F35 FMC1_HPC_HB16_N N26
E37 FMC1_HPC_HB21_N P23 F37 FMC1_HPC_HB20_P P21
E39 VADJ F38 FMC1_HPC_HB20_N N21
F40 VADJ
Table 1-27: J35 VITA 57.1 FMC 1 HPC Connections (Cont’d)
J35
FMC 1
HPC Pin
Schematic Net Name
U1 FPGA
Pin
J35
FMC 1
HPC Pin
Schematic Net Name
U1 FPGA
Pin
Send Feedback
