Xilinx VC707 User Manual

VC707 Evaluation Board www.xilinx.com 61
UG885 (v1.4) May 12, 2014
Feature Descriptions
C2 FMC1_HPC_DP0_C2M_P E2 D1 PWRCTL1_VCC4B_PG AL32
C3 FMC1_HPC_DP0_C2M_N E1 D4 FMC1_HPC_GBTCLK0_M2C_P A10
C6 FMC1_HPC_DP0_M2C_P D8 D5 FMC1_HPC_GBTCLK0_M2C_N A9
C7 FMC1_HPC_DP0_M2C_N D7 D8 FMC1_HPC_LA01_CC_P J40
C10 FMC1_HPC_LA06_P K42 D9 FMC1_HPC_LA01_CC_N J41
C11 FMC1_HPC_LA06_N J42 D11 FMC1_HPC_LA05_P M41
C14 FMC1_HPC_LA10_P N38 D12 FMC1_HPC_LA05_N L41
C15 FMC1_HPC_LA10_N M39 D14 FMC1_HPC_LA09_P R42
C18 FMC1_HPC_LA14_P N39 D15 FMC1_HPC_LA09_N P42
C19 FMC1_HPC_LA14_N N40 D17 FMC1_HPC_LA13_P H39
C22 FMC1_HPC_LA18_CC_P M32 D18 FMC1_HPC_LA13_N G39
C23 FMC1_HPC_LA18_CC_N L32 D20 FMC1_HPC_LA17_CC_P L31
C26 FMC1_HPC_LA27_P J31 D21 FMC1_HPC_LA17_CC_N K32
C27 FMC1_HPC_LA27_N H31 D23 FMC1_HPC_LA23_P P30
C30 FMC1_HPC_IIC_SCL U52.4 D24 FMC1_HPC_LA23_N N31
C31 FMC1_HPC_IIC_SDA U52.3 D26 FMC1_HPC_LA26_P J30
C34 GND D27 FMC1_HPC_LA26_N H30
C35 VCC12_P D29 FMC1_HPC_TCK_BUF U19.14
C37 VCC12_P D30 FMC_TDI_BUF U19.18
C39 VCC3V3 D31 FMC1_TDO_FMC2_TDI U27.2
D32 VCC3V3
D33 FMC1_HPC_TMS_BUF U19.17
D34 NC
D35 GND
D36 VCC3V3
D38 VCC3V3
D40 VCC3V3
Table 1-27: J35 VITA 57.1 FMC 1 HPC Connections (Cont’d)
J35
FMC 1
HPC Pin
Schematic Net Name
U1 FPGA
Pin
J35
FMC 1
HPC Pin
Schematic Net Name
U1 FPGA
Pin
Send Feedback
