Xilinx ZCU102

Optional Hardware Setup
˃ Connect PMOD headers
˃ Both J55 and J87:
1 to 2
3 to 4
5 to 6
7 to 8
˃ Connect the PROTO
header, J3
6 to 8
10 to 12
14 to 16
18 to 20
22 to 24
Note: Presentation applies to the ZCU102
