Xilinx ZCU102

Optional Hardware Setup
˃ Mictor Loopback Test
www.zebax.com
Mictor Breakout Adapter Plug
Part # ZX104LN
˃ Jumper odd side as follows:
7 to 11
15 to 19
23 to 27
31 to 35
9 to 13
17 to 21
25 to 29
33 to 37
Note: Presentation applies to the ZCU102
