Zynq UltraScale+ VCU TRD User Guide 40
UG1250 (v2019.1) May 29, 2019 www.xilinx.com
Chapter 3: APU Software Platform
Audio Setting
The Audio Settings panel is shown in Figure 3-14 and described in Tab le 3 -6 .
X-Ref Target - Figure 3-14
Figure 3-14: Audio Setting Panel
Table 3-6: Audio Settings
Parameter Setting
Enable Audio Enable or disable audio in pipeline.
Format Audio format. Currently S24_32LE format is supported.
Channel Number of audio channels. Currently two channels are supported.
Sampling Rate Audio sampling rate. Currently 48000 is supported.
Volume Audio volume. Ranges from 0 to 10, default value is 2.
Source Available sources are HDMI and I2S
Renderer Available renderers are DP and I2S
