Xinje DF3E Series User Manual

147
Parameter
Function
Unit
Default value
Range
Effective
Suitable
mode
Reference
chapter
2-P+D
P0-11
～
P0-12
Number of instruction
pulses per cycle
0: Electronic gear ratio
Non-0: Number of
command pulses
required for motor
rotation
1 pul
10000
0~999999
99
○
5|6
4.3.1.1
P0-13
Electronic Gear
Numerator
-
1
0~65535
○
5|6
4.3.1.1
P0-14
Denominator of
Electronic Gear
-
1
0~65535
○
5|6
4.3.1.1
P0-15
Pulse frequency
corresponding to rated
speed
100Hz
1000
1~10000
○
7
4.4.3.2
P0-16
Speed command pulse
filter time
0.01ms
100
0~10000
○
7
4.4.3.3
pulse
offset limit
pulse offset limit
0.01
turn
2000
0~65535
√
5|6
4.3.1.6
P0-24
Type selection of
discharge resistance
(version 3640 and before)
0: built in
1: external
Power protection mode
of discharge resistance
(version 3700 and later)
0 - cumulative discharge
time
1 - average power mode 1
2-average power mode 2
-
0
0~1
○
1|3|5|6|7|
4.2.6
P0-25
Power Value of
Discharge Resistance
W
100
1~65535
○
1|3|5|6|7
4.2.6
P0-26
Discharge resistance
value
Ω
80
1~500
○
1|3|5|6|7
4.2.6
P0-27
Servo shutdown the
enable stop mode
0-Inertial Operation Stop
2-deceleration stop
-
0
0~5
○
1|3|5|6|7|
4.2.4
P0-28
Servo Overrun Stop
Mode
(P0-28.0)
0-deceleration stop 1
1-Inertial Stop
2-deceleration stop 2
3-Alarm Stop
Overtravel alarm shield
switch (P0-28.1)
0-not shield the alarm
1-shield the alarm
-
2
0~3
○
1|3|5|6|7
4.2.4
0
0~1
P0-29
Servo Alarm Stop Mode
0-Inertial Operation Stop
2-deceleration stop
-
2
0~2
○
1|3|5|6|7|
4.2.4
P0-30
stop timeout time
1ms
20000
0~65535
○
1|3|5|6|7|
4.2.3
P0-31
Deceleration stop time
1ms
25
0~5000
○
1|3|5|6|7
4.2.3
P0-33
Set the motor code
-
0
0~ffff
●
1|3|5|6|7
4.7
