Xinje DF3E Series User Manual

148
Parameter
Function
Unit
Default value
Range
Effective
Suitable
mode
Reference
chapter
P0-53
Read motor parameter
alarm shield bit
0- not shield alarm
shield alarm
-
0
0~1
●
1|3|5|6|7
-
P0-69
Fan switch (
P0-69.0)
0- Turn on the fan when
the temperature greater
than 45
℃
and turn off
the fan when less than
42
℃
(hysteresis 3
℃
)
1 - Turn on the fan after
enabling, turn off the fan
when not enabling
Large motor
thermocouple break alarm
shield switch (P0-69.1)
0-shield thermocouple
disconnection alarm
1-thermocouple
disconnection
-
1
0~1
√
1|3|5|6|7
-
0
0~1
P0-74
Blocking alarm time
ms
0
0~5000
√
1|3|5|6|7
4.8.1
P0-75
Blocking alarm speed
rpm
50
5~9999
√
1|3|5|6|7|
4.8.1
P0-79
Absolute Encoder
Battery Undervoltage
Alarm Switch (firmware
version 20160304 and
later)
0-used as absolute value
encoder
1-1-used as incremental
encoder
2-used as absolute value
encoder, ignoring multi
turn overflow alarm
-
1
0~2
●
1|3|5|6|7|
4.7.1
P0-80
Thermal Power Protection
of Motor
0-current protection
1-Average Thermal
Power Protection
2-Analog Thermal Power
Protection
-
2
0~2
●
1|3|5|6|7|
-
P0-92
～
P0-93
32-bit electronic gear ratio
numerator.
take effect when P0-11
～
P0-14 is 0. P0-92*1 +
P0-93 *10000
-
1
1~9999
○
5|6
4.3.1.1
1~65535
P0-94
～
P0-95
32-bit electronic gear ratio
denominator.
take effect when P0-11
～
P0-14 is 0. P0-94*1 +
P0-95 *10000
-
1
1~9999
○
5|6
4.3.1.1
1~65535
