Xinje DF3E Series

153
Parameter
Function
Unit
Default value
Range
Effective
Suitable
mode
Reference
chapter
P3-30
external forward
torque limit
%
300
0~1000
√
1|3|5|6|7
4.8.2
P3-31
external reverse torque
limit
%
300
0~1000
√
1|3|5|6|7
4.8.2
P3-32
Brake torque
1%
300
0~1000
√
1|3|5|6|7
4.2.4
P3-33
Preset torque
%
0
-1000~1000
√
1
4.5.1.1
P3-38
Anti blocking forward
torque limit
%
300
0~1000
√
1|3|5|6|7
4.8.1
P3-39
Anti blocking reverse
torque limit
%
300
0~1000
√
1|3|5|6|7
4.8.1
P3-45
Torque mode
switching delay
ms
40
0~9999
√
1
-
P4-XX:
Parameter
Function
Unit
Default
value
Range
Effective
Suitable
mode
Reference
chapter
P4-00.0
Z phase signal numbers
The Z phase signal numbers after
leaving the limit switch (note: stop
when N+1 Z phase signal reached)
pcs
2
0~f
○
5|6
4.3.1.8
P4-00.1
Search the origin function
0-OFF
1-ON
-
0
0~1
○
5|6
4.3.1.8
P4-00.2
return to zero overrun prohibition
0-not prohibit
1-prohibit
-
0
0~1
○
5|6
4.3.1.8
P4-01
Speed of hitting the proximity
switch
rpm
600
0~65535
○
5|6
4.3.1.8
P4-02
Speed of leaving proximity switch
rpm
100
0~65535
○
5|6
4.3.1.8
P4-03.0
Internal Location Given Mode Sets
Location Mode
0-relative positioning
1-Absolute positioning
-
0
0~1
○
5
4.3.3.1
P4-03.1
Internal Position-Given Mode Sets
Step Change Mode
0-step-changing when signal is ON,
recyclable
1-change step at signal rising edge,
single step execution
2-starting at Signal rising edge,
sequential execution of all, no cycle
3-set segment no. through
communication
4-/CHSTP dual edge triggerring
5-terminal/PREFA(P5-57),
/PREFB(P5-58), /PREFC(P5-59)
select the segment no., range 1~3
6-terminal/PREFA (P5-57),
/PREFB(P5-58), /PREFC(P5-59)
select segment no., range 1~8
-
0
0~6
○
6
4.3.3.1
P4-03.2
Internal position mode sets waiting
mode
-
0
0~1
○
5
4.3.3.1
