Xinje DF3E Series User Manual

154
Parameter
Function
Unit
Default
value
Range
Effective
Suitable
mode
Reference
chapter
0-wait positioning completion
1-not wait positioning completion
P4-04
Valid segment number
-
0
0~35
○
5
4.3.3.2
P4-08
Internal position mode start segment
No
-
1
0~35
○
5
4.3.3.3
P4-10
～
P4-11
First segment pulse
1pul
0
-327689999~
327679999
√
5
4.4.3
P4-12
First segment speed
0.1rpm
0
0~65535
√
5
4.4.3
P4-13
First segment acceleration time
1ms
0
0~65535
√
5
4.4.3
P4-14
First segment deceleration time
1ms
0
0~65535
√
5
4.4.3
P4-16
Adjusting time
1ms
0
0~65535
√
5
4.4.3
P4-10+
（
n-1
）
*7 ~
P4-16+
（
n-1
）
*7
segment 1 to 35 pulse parameters (n
is segment number)
-
-
-
√
5
4.4.3
P5-XX:
Parameter
Function
Unit
Default
value
Range
Effective
Suitable
mode
Reference
chapter
P5-00
Positioning completion
width/COIN
Comman
d unit
11
1~65535
√
5|6|10
4.3.1.2
P5-01
Location Completion
Detection Mode
-
0
0~3
√
5|6|10
4.3.1.2
P5-02
Location completion retention
time
ms
0
0~65535
√
5|6|10
4.3.1.2
P5-03
Rotation Detection Speed
rpm
50
0~10000
√
1|3|5|6|7
4.8.5.2
P5-04
Same speed detection speed
rpm
50
0~10000
√
1|3|5|6|7
4.8.5.3
P5-05
Reached detection speed
rpm
1000
0~10000
√
1|3|5|6|7
4.4.1.3
P5-06
Positioning near output width
Comman
d unit
50
1~65535
√
5|6
4.3.1.3
P5-07
Servo OFF delay time
ms
500
-500~9999
○
1|3|5|6|7
4.2.5
P5-08
Brake instruction output speed
rpm
30
20~10000
○
1|3|5|6|7
4.2.5
P5-09
Brake instruction waiting time
ms
500
0~65535
○
1|3|5|6|7
4.2.5
P5-10
user-defined output 1 trigger
condition
-
0
0~ffff
√
1|3|5|6|7
4.8.5.7
P5-11
Set a value that compares with
the trigger condition of custom
output 1
Relating
to trigger
condition
0
-9999~9999
√
1|3|5|6|7
4.8.5.7
P5-12
Select custom output 1 mode
-
0
0~3
√
1|3|5|6|7
4.8.5.7
P5-13
Setting custom output 1
hysteresis
Relating
to trigger
condition
0
0~65535
√
1|3|5|6|7
4.8.5.7
P5-14
Custom Output 2 Trigger
Condition
-
0
0~ffff
√
1|3|5|6|7
4.8.5.7
P5-15
Set a value that compares with
the trigger condition of custom
output 2
Relating
to trigger
condition
0
-9999~9999
√
1|3|5|6|7
4.8.5.7
P5-16
Select custom output 2 mode
-
0
0~3
√
1|3|5|6|7
4.8.5.7
P5-17
Setting custom output 2
hysteresis
Relating
to trigger
condition
0
0~65535
√
1|3|5|6|7
4.8.5.7
P5-18
SI filter time multiple
-
1
0~10000
√
1|3|5|6|7
4.8.4.1
