Xinje DS5K Series User Manual

1
2
3
4
5
6
No.
Definition
40, 60, 80 flange S02 motor
1
PE
2
U
3
V
4
W
5
BK+
6
BK-
4
1
2
3
No.
Definition
40, 60, 80 flange B2 motor
1
U
2
V
3
W
4
PE
Connector pins
Interface definition
Suitable model
No.
Definition
1
3
4
5
6
7
2
1
PE
MS5-130 flange medium motor with
brake, MS6-100, 130 flange motor with
brake
2
U
3
V
4
W
5
BK+
6
BK-
7
/
1
34
5
6
2
No
Definition
40, 60, 80 flange B2 brake motor
1
U
2
W
3
V
4
PE
5
BK+
6
BK-
front outgoing reverse outgoing
No
Definition
40 flange B3 motor
1
W
2
V
3
U
4
PE
5
BK+
6
BK-
front outgoing reverse outgoing
No
Definition
60, 80 flange B3 motor
1
U
2
V
3
W
4
PE
5
BK+
6
BK-
Brake pins:
The cable including BK pin is used for the brake motor. The cable of the non-brake motor has no BK
pin.
