Xinje DS5K Series User Manual

5.3.1.4 Command pulse prohibition (/INHIBIT)
Position command prohibition, including internal and external position commands. Stop the function of
command pulse input during position control. When the /INHIBIT signal is on, the pulse command is
no longer counted.
◼ Related parameters
Parameter
Signal
name
Default
setting
Suitable
mode
Meaning
Modify
Effective
P5-32
/INHIBIT
n.0000
All
Command pulse prohibition
Anytime
At once
Parameter range n.0000-0015, assigned to other input terminals by parameter P5-32.
If it is necessary to input from SI2, P5-32 can be set to n.0002/0012. Refer to section 3.2.2 for hardware
wiring details.
1. /INHIBIT terminal effectiveness description
Parameter setting
status
Signal/INHIBIT terminal input status
Signal/INHIBIT terminal
logic
P5-32=n.0000
No external terminal input
Invalid
P5-32=n.000□
SI□ terminal has no signal input
P5-32=n.001□
SI□ terminal has signal input
P5-32=n.0010
No external terminal input
Valid
P5-32=n.000□
SI□ terminal has signal input
P5-32=n.001□
SI□ terminal has no signal input
2. The influence of /INHIBIT terminal signal on the running state of motor
Control mode
Motor operation status
/INHIBIT terminal logic
valid
/INHIBIT terminal logic invalid
5- internal position
control
Pause current segment
/INHIBIT signal is from ON→OFF, continue
running from pause point.
6- external pulse
position control
Pause pulse command
reception
/INHIBIT signal is from ON→OFF, continue
running from the pulse command received
after OFF.
5.3.1.5 Offset clear（/CLR）
Position offset=(position command – position feedback)(encoder unit)
The position deviation clearing function means that the driver can clear the position deviation
when the servo is off or the /CLR signal is received.
◼ Related parameters
Parameter
Signal
name
Default
setting
Suitable
mode
Meaning
Modify
Effective
P5-34
/CLR
n.0000
All
Pulse deviation clear
Anytime
At once
Parameter range n.0000-0015, assigned to other input terminals by parameter P5-34.
If it is necessary to input signal from SI2, P5-34 can be set to n.0002/0012. Refer to section 3.2.2 for
hardware wiring details.
1. /CLR signal effectiveness
parameter setting status
Signal /CLR terminal input status
Signal /CLR terminal
logic
P5-34=n.0000
No external terminal input
Invalid
P5-34=n.000□
SI□ terminal has no signal input
P5-34=n.001□
SI□ terminal has signal input
P5-34=n.0010
No external terminal input
Valid
P5-34=n.000□
SI□ terminal has signal input
P5-34=n.001□
SI□ terminal has no signal input
