Xpresskit DBALL User Manual

Page 8
Installation Type 2b (without T-Harness)
With the exception of the OBDII Diagnostic connector, all adapters are displayed from the wire side (unless specified otherwise).
Important!
The Hood Pin and Remote Start Safety Override Switch are mandatory safety devices, but are NOT supplied with the DBALL.
[1] STSW: Starter Switch Wire. Refer to the wiring reference chart on page 9 for wire colors and connections
[2] This connection is only required when the EIPS (Engine Idle Protection System) feature is activated.
Diagnostic
Connector at OBDII
(connector side view)
RF
Prog. Button
LED
White Conn.
At main body ECU
12
356
78910
4
4
2
10
14 12
HS CAN High: Tan/Black: 3
HS CAN Low: Tan: 4
(+) 12V: Brown: 7
[1] (+) STSW Output: Yellow: 8
(-) Ground: Black: 14
(+) 12V: Red: 13
1 8
169
(-) Parking Lights: pin 18
White Connector
At headlight switch
12345678910
1112131415161720
19
18
10
Hood Pin
Neutral Safety Switch
6: White/Black: (-) Hood
(-) Parking Lights Output: Red/Black: 4
(-) Push-to-Start Output: Green/Black: 2
[2] (-) EIPS Fail Output: Black/White: 1
10
11
12987
1 2 3 4 5 6
Black Horn Connector
at the bottom of steering column
1
5
4
3 1
811
12
10
9
14
6
13
2
ENGINE
START
STOP
7
Black
Connector
Note: Hood pin only required on
vehicle not equipped with a factory
hood pin.
You can connect to either a XL202
RFTD OR a SmartStart module.
Refer to the SmartStart/XL202
Installation Notes for more
information.
Connection required only if PitStop/Idle
mode or EIPS is desired (see details in
Quick Reference Guide).
(connector side view)
Refer to the Wiring Reference Chart section on page 9 for more information on specific wiring and connections.
[2] EIPS to Horn: pin 8
(-) Push-to-Start: pin 7
[1] (+) STSW: pin 4 or 6
(+) 12V: pin 16
(-) Ground: pin 4
HS CAN High: pin 6
HS CAN Low: pin 14
DBALL/
DBALL2
Platform: DBALL/DBALL2
Firmware: TL1 Remote Start Ready (RSR) Installation
© 2015 Directed. All rights reserved.
Rev.: 20150709
Vehicles
2013 2012 2011 2010 2009 2008 2007 PK-Immobilizer Bypass-Data No Key Req'd DL-Arm Factory Security DL-Disarm Factory Security DL-Door Lock Control DL-Door Unlock DL-Driver Priority Unlock DL-Hatch Glass Release DL-Trunk / Hatch Release EIPS RS-Remote Start Ready RS-SmartStart RS-Tach / RPM Output SS-Entry Monitoring ALL Door Pins SS-Entry Monitoring Driver Door Pin SS-Entry Monitoring Hood Pin SS-Entry Monitoring Trunk/Hatch Pin SS-Factory Alarm Trigger Monitoring ST-Brake Status (foot brake) ST-Ignition Status
ES 350 (Smart Key) 2 2 2 2 2 2 • • • • • • • • • • • • • • • • • •
Camry (Smart Key) 2 2 2 2 2 • • • • • • • • • • • • • • • • • •
Camry Hybrid 2 2 2 2 2 • • • • • • • • • • • • • • • • • •
Corolla (Smart Key) 1 1 1 1 1 • • • • • • • • • • • • • • • • • •
Highlander (Smart Key) 2 2 2 2 2 2 • • • • • • • • • • • • • • • • • •
Highlander Hybrid 2 2 2 2 2 2 • • • • • • • • • • • • • • • • • •
RAV4 (Smart Key) 1 1 1 1 • • • • • • • • • • • • • • • • •
Legend:
PK: Transponder & Immobilizer Override
DL: OE Door Lock & Alarm Controls
EIPS: Engine Idle Protection System
RS: Remote Start & Engine Controls
SS: Integrated Security & Monitoring
ST: Function/Feature Status
Toyota
Lexus
