Xprinter R330H - Dismantlement of Front Cover of the Printer

24
6.1.2 Dismantlement of the Front Cover of the Printer
First take off the bottom cover of the
printer
A. Take off L-shaped foot pads.
B. Dismantle the two H3*6mm screws for
fixing the base with a cross screwdriver,
and then take off the base in the same
direction.
Illustration
Dismantle the two H3*6mm screws for
fixing the front cover with a cross
screwdriver.
2
3
1
