Xtralis XAS-2-USProduct Guide Xtralis Pty Ltd
Pipe network components required for open area applications are ordered separately. Refer to Table3-4 for further
information.
Name Part Number Description
CPVC Pipe VP-P-210 Diameter = 3/4", Length = 210', Orange CPVC Pipe
CPVC Pipe VP-P-420 Diameter = 3/4", Length = 420', Orange CPVC Pipe
Union VP-UNION Diameter = 3/4", Qty.= 15
Coupling VP-COUP Diameter = 3/4", Qty.= 15
45º Elbow VP-ELB-45 Diameter = 3/4", Qty.= 10
90º Elbow VP-ELB-90 Diameter = 3/4", Qty.= 20
Tee VP-TEE Diameter = 3/4", Qty.= 15
Pipe End Cap VP-EC Diameter = 3/4", Qty.= 25
Solvent Cement VP-CEMENT 1 Pint
Baffle 06-AP10 Baffle for Apollo Point Detector.
Refer to Section 2.3.1 on page 11 for further information.
Baffle 06-HK10 Baffle for Hochiki Analog ALK-V Point Detector.
Refer to Section 2.3.1 on page 11 for further information.
Baffle 06-HK30 Baffle for Hochiki Analog ALN-V(H) Point Detector.
Refer to Section 2.3.1 on page 11 for further information.
Baffle 06-HK40 Baffle for Hochiki SLV-24V Point Detector.
Refer to Section 2.3.1 on page 11 for further information.
Baffle 06-SE10 Baffle for Siemens Point Detector HFP-11.
Refer to Section 2.3.1 on page 11 for further information.
Baffle 06-SE20 Baffle for Siemens Point Detectors FDO421 and OP921.
Refer to Section 2.3.1 on page 11 for further information.
Baffle 06-SE30 Baffle for Siemens Point Detectors FDOOT441, OOH941,
FDOOTC441 and OOHC941.
Refer to Section 2.3.1 on page 11 for further information.
Baffle 06-NF10 Baffle for Notifier FSP-851, FSA-851A and Johnson Controls
A2951JA detectors.
Refer to Section 2.3.1 on page 11 for further information.
Baffle 06-HN10 Baffle for the following Honeywell detectors:
l System Sensor 2251B or 2251BA
l Notifier - Fire Warden NP-100 or NP-100A
l Gamewell/FCI ASD-PL2F or ASD-PL2FA
l Silent Knight IDP-PHOTO or SK-PHOTO
l Firelite SD355 or SD355A
l Honeywell TC806B1076 or TC806B1076CDN
l JCI 2951J or 2951JA
Refer to Section 2.3.1 on page 11 for further information.
Blanking Baffle 06-0000 Baffle for unused XAS-2-US chamber
Air Inlet Filter 80-0020-0 Filter element coarse FRS20
Sampling Hole Label E700-SPLR
Fuse 34-1251-T3 1.25 A, Anti-surge fuse
Table3-4: XAS-2-US Open Area Application Accessories List
24 www.xtralis.com
