Xycom 9462 - Display; Diagnostic LEDs; Function and User-Defined Keys; Keyboard Port (9460 KP;9462 KP) (front access)

9460/9460KP/9462/9462KP System Manual
3-4
Feature Description
Display The 9460KP/9462KP comes with a 10.4-inch (640 x 420) STN
or TFT flat-panel display or a 12.1-inch SVGA (800 x 600) STN
or TFT flat-panel display.
Diagnostic LEDs The 9460KP/9462KP features status LEDs on the front panel,
which allow you to monitor system operation. Following is a de-
scription of the LEDs and what it means when they're lit:
Power Lit when the system has power
Disk Lit when the computer is accessing the disk drive
COM Lit when there is communication activity on one of the
serial ports, including communication between the com-
puter module and the touch screen (if on COM2) or a se-
rial mouse.
Input Lit when the unit has a touch screen; the LED gets
brighter when a touch input is detected or a key is
pressed.
F/A key Indicates the keypads are in alpha mode
Function and User-Defined Keys These 38 relegendable function keys (76 using the F/A keys)
provide easy access to familiar routines. (F/A keys can be used
for alpha and symbol entry). See the
Customizing Keypad In-
serts
section in this chapter for details on customizing your key-
pad inserts.
Numeric/Cursor Control Keypad The purpose of data entry keypads are for entering data and
moving the cursor.
F/A Key (Contrast Control) If the LED is lit, alpha characters are returned. While holding
down the F/A key and pressing the cursor control keys, contrast
can be adjusted (STN displays only).
PF10 Key (Keypad Configuration Key) This key reconfigures your keypad.
Keyboard Port (9460KP/9462KP)
(front access)
The 9460KP/9462KP provides both front and rear accessible
PS/2 keyboard connectors. The front accessible connector is
located on the lower right side of the front panel. The rear ac-
cessible connector is located on the side of the unit.
Note
: Only one keyboard port on the 9460KP/9462KP can be
used at a time.
Note
: The installation of the touch screen driver determines
whether a second pointing device will function correctly. If you
are using a mouse with a touch screen, please review the
Touch Screen Driver Installation instructions.
