Xycom 9462 - Appendix A - Technical Specifications; Hardware Specifications

A-1
Appendix A – Technical Specifications
Hardware Specifications
9460/9460KP/9462/9462KP Hardware Specifications
Characteristic Specification
Mechanical
Height
Width
Depth
Weight
11.0" Front Panel; 14" (KP units)
13.0" Front Panel 19" (KP units)
6.5" overall
5.75" behind front panel
0.75" front panel protrusion
7.25" overall with back-mounted external floppy
16 lbs; 18 lbs with external floppy
Electrical
AC
DC
115/230 VAC 50-60 Hz 3.0/1.5 AMPS
20-36 VDC 24 V nominal 10 A maximum
Power Supply 80 watts
Available Power With AHIP4+ CPU board*
+ 5 V @ 30.9W 6.17A
+12 V @ 22.6W 1.88A
-5 V plus -12 V @ 8.5W 0.71A
Caution: Total expansion power not
to exceed 46 watts.
* Based on Am5x86 133 MHz
Processor
With AHIP5+ CPU board*
+ 5 V @ 7.7W 1.54A
+12 V @ 21.84W 1.82A
-5 V plus -12 V @ 8.64W 0.72A
Caution: Total expansion power not
to exceed 36 watts.
* Based on 200 MHz MMX Pentium
Processor
Passive Backplane Two PC/AT bus ¾ length expansion slots
One PCI or PC/AT bus ¾ length expansion slot
Mounting Panel Mount or 19” rack with optional filler plate.
Flat Panel 10.4" STN passive color display
10.4" TFT active color display
12.1" STN passive color display
12.1" TFT active color display
Agency Approvals UL 1950
UL 1604
CUL C22.2, No. 950
CUL C22.2, No. 213
Regulatory Compli-
ance
FCC 47 CFR. Part 15, Class A
CE
EMI EN55022: 1994 Class A
IMMUNITY EN50082-2:1995
SAFETY EN60950
